Airtac PSL Throttle Speed Control Fitting PSL1002AD
2、Precisely controls operational speed of pneumatic actuators and pressure signal transmission efficiency;
3、Superior flow characteristics with high sensitivity and precise micro-adjustment capabilities;
4、Exhaust throttle and intake throttle configurations available for compatibility with diverse actuator models;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention;
6、Adjustment lever features an anti-drop structural design;
7、Integrated PT thread adhesive ensures leak-proof sealing at threaded connections;
Category: L-Type Throttle Valve Fittings | Brand: AirTAC | Series: PSL
AirTAC PSL Series Throttle Speed Controller PSL1002AD Specifications
- Model: PSL1002AD
- Type: One-way throttle with check valve (adjustable flow control)
- Thread size: 1/8" BSPP (G1/8)
- Body material: Nickel-plated brass
- Seal material: NBR (Nitrile rubber)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 350 L/min (ANR)
- Temperature range: -5℃ to 80℃
- Adjustment range: 20-180° rotation (0.2-8 L/min fine tuning)
- Weight: 38g ±1g
- Dimensions: 32mm(L) × 18mm(W) × 18mm(H)
- Pressure drop: ≤0.02 MPa at max flow
- Vibration resistance: 10-55Hz (1.5mm amplitude)
Precision bidirectional flow control valve with integrated check function, featuring micro-flow adjustment capability through its graduated rotary knob. The anti-corrosion nickel plating ensures durability in humid environments. Designed for stable flow regulation even under pressure fluctuations.
- Pneumatic cylinder speed synchronization systems
- Assembly line clamping force adjustment
- Medical gas flow control devices
- Packaging machine actuator timing regulation
- Automated test equipment pressure balancing
Installation note:
Install vertically with flow arrow aligned. For air exhaust control,
pair with reverse-mounted check valve. Lubricate threads with PTFE tape
and torque to 12-15N·m. Perform flow calibration after 50 operation cycles.
