Airtac PSL Throttle Speed Control Fitting PSL1002AD-S
2、Precisely controls operational speed of pneumatic actuators and pressure signal transmission efficiency;
3、Superior flow characteristics with high sensitivity and precise micro-adjustment capabilities;
4、Exhaust throttle and intake throttle configurations available for compatibility with diverse actuator models;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention;
6、Adjustment lever features an anti-drop structural design;
7、Integrated PT thread adhesive ensures leak-proof sealing at threaded connections;
Category: L-Type Throttle Valve Fittings | Brand: AirTAC | Series: PSL
AirTAC PSL Flow Control Throttle Fitting PSL1002AD-S Specifications
- Model: PSL1002AD-S
- Type: Adjustable one-way throttle valve with check function
- Port size: 1/8" NPT (G1/8 optional)
- Body material: Nickel-plated brass
- Seal material: NBR (Nitrile rubber)
- Flow adjustment range: 0-900 L/min (ANR)
- Operating pressure: 0.05-0.8 MPa
- Temperature range: -5℃ to 60℃
- Installation orientation: Bidirectional (horizontal/vertical)
- Weight: 48g ±2g
- Dimensions: 32mm(L) × 22mm(W) × 23mm(H)
- Thread engagement depth: 8mm
- Protection rating: IP40 (non-immersed applications)
- Filter requirement: 25μm or finer upstream
Precision throttle valve with integrated check valve functionality, designed for precise airflow regulation in pneumatic systems. Features dual-scale flow indicators (0-10 adjustment marks with 5μm graduation) and tool-free adjustment via knurled knob. The nickel-plated construction ensures corrosion resistance in humid environments.
- Cylinder speed control in automation lines
- Pneumatic gripper actuation timing
- Vacuum generator flow regulation
- Medical device pneumatic circuits
- Packaging machine air cushion adjustment
Installation note:
For optimal performance, install directly at cylinder ports using 15mm wrench flats.
Complete 3 full counterclockwise turns before initial adjustment. Lubricate with ISO VG32
pneumatic oil if used in high-cycle applications (>1Hz).
| Property | Property Value |
|---|---|
| sku | PSL1002AD-S |
