Airtac PSS Exhaust Throttle Type Universal Speed Control Valve PSS1002B
AirTAC PSS1002B Exhaust Throttle Type Universal Speed Control Valve Specifications
- Model: PSS1002B
- Type: Exhaust throttle type with 360° adjustable knob
- Port size: PT1/8 (M5×0.8 optional)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 250 L/min (ANR)
- Temperature range: 5℃ to 60℃ (with anti-freeze measures below 0℃)
- Installation orientation: Any direction (omnidirectional mounting)
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR (Nitrile rubber)
- Weight: 195g ±5g
- Dimensions: 48mm(L) × 34mm(W) × 40mm(H)
- Thread depth: 10mm (male thread engagement)
- Pressure drop: ≤0.02 MPa at rated flow
- Repeat accuracy: ±5% of set flow rate
- Protection rating: IP54 (standard dust/water resistance)
- Compatible fluids: Clean compressed air (ISO 8573-1:2010 Class 3)
Precision flow control valve featuring bidirectional exhaust throttling with lockable rotary knob. The universal joint design allows flexible installation in confined spaces. Built with corrosion-resistant aluminum housing and precision-machined brass orifice for stable flow regulation across 5 full turns of adjustment.
- Pneumatic cylinder speed control in automation lines
- Exhaust flow regulation for shock absorption
- Packaging machine actuator synchronization
- Medical equipment pneumatic braking systems
- Semiconductor handling robot end-effectors
Installation note:
Apply 56-75 N·cm torque during port connection. For vertical installations,
position flow control knob upward to prevent debris accumulation.
Always install downstream of lubricator when using oil-mist lubrication systems.
- Clean filter screen every 2,000 operation hours
- Re-lubricate adjustment thread annually with silicone grease (ASG-30)
- Replace O-rings after 500,000 cycles or 5 years
| Property | Property Value |
|---|---|
| sku | PSS1002B |
