Airtac PSS Exhaust Throttle Type Universal Speed Control Valve PSS1203A
AirTAC PSS1203A Exhaust Throttle-Type Universal Speed Controller Specifications
- Model: PSS1203A
- Type: Uni-directional exhaust throttle with 360° adjustable knob
- Port size: 1/8" NPT (G1/8 optional)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 200 L/min (ANR)
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Mounting type: Panel mount or direct cylinder port connection
- Adjustment range: Full shut-off to max flow (50-100% linear control)
- Weight: 85g ±2g
- Dimensions: 38mm(W) × 38mm(H) × 52mm(L)
- Protection rating: IP54 (standard sealing)
- Vibration resistance: 10–55Hz with 1.5mm amplitude
High-precision exhaust-side flow control valve featuring omnidirectional mounting capability and tamper-resistant knob design. The chrome-plated brass adjustment screw ensures smooth throttling operation across 300+ full rotation cycles. Integrated dust cap maintains seal integrity in particle-heavy environments.
- Pneumatic cylinder speed regulation in pick-and-place systems
- Exhaust flow control for vacuum generators
- Medical bed actuator synchronization
- Textile machinery tension adjustment
- Food processing pneumatic timing circuits
Operation tip:
For precise adjustment, rotate knob clockwise to decrease exhaust speed.
Always perform flow calibration under actual operating pressure.
Compatible with ISO 8573-1:2010 [2:4:2] class compressed air.
| Property | Property Value |
|---|---|
| sku | PSS1203A |
