Airtac PTB Single Acting Pen-Type Cylinder PTB10X10SR
2. Compact miniature design with minimized footprint and lightweight construction
3. High-precision piston rod guidance (guide bearings require no additional lubrication)
4. Front mounting only for PB4/PB6 models; front/rear mounting options available for PB10/PB12/PB16
5. Stainless steel piston rod and cylinder body for corrosion resistance in harsh environments
6. Multiple configurations and mounting accessories available for customized solutions
7. Small bore size ensures rapid response and high-frequency operation capability
Category: Pen-type Cylinders, Brand: Airtac, Series: PTB
AirTAC PTB Series Single-Acting Pen-Type Cylinder PTB10X10SR Technical Details
- Model: PTB10X10SR
- Type: Single-acting spring return (push type)
- Bore size: 10mm
- Stroke: 10mm (±1mm tolerance)
- Operating pressure: 0.05–0.8 MPa
- Port thread: M5×0.8 (standard) / PT1/8 optional
- Cushioning: Adjustable rubber buffer
- Mounting style: Single-end male thread (M5×0.8)
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.12kg (excluding accessories)
- Dimensions: 30mm(L) × 20mm(W) × 15mm(H) (cylinder body)
- Full length: 50mm (including rod at retracted position)
- IP rating: IP40 (standard)
- Built-in magnet: Yes (SR suffix indicates magnetic piston)
Ultra-compact pen-shaped cylinder designed for precision linear motion in confined spaces. Features chrome-plated piston rod for corrosion resistance and smooth operation. The SR variant includes embedded magnets for position sensing compatibility with reed switches. Requires 40μm filtered air with ISO VG32 lubricator oil (optional oil-free operation).
- PCB component insertion machines
- Medical device actuator mechanisms
- Semiconductor wafer handling systems
- Precision clamping in watch assembly
- Automated cosmetic dispenser pumps
- Laboratory sample positioning stages
Installation guidelines:
Maximum lateral load ≤0.3N. For vertical mounting, ensure spring chamber faces downward to prevent moisture accumulation. Magnetic sensor installation requires 0.5-1mm gap adjustment. Lubricate every 500km travel distance under normal conditions.
| Property | Property Value |
|---|---|
| sku | PTB10X10SR |
| Rear Cover Type | Axial Port Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
