Airtac QCKR Rotary Clamping Cylinder QCKR12X10SM
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR12X10SM Specifications
- Model: QCKR12X10SM
- Type: Double-acting rotary clamping cylinder
- Bore size: 12mm (ISO 6432 standard)
- Stroke: 10mm ±0.5mm
- Operating pressure: 0.1–0.8 MPa
- Maximum torque: 0.35 N·m @ 0.6 MPa
- Rotation angle: 90° ±2° (clockwise/counter-clockwise)
- Port size: M5×0.8 (standard), G1/8 optional
- Operating temperature: -20℃ to 80℃
- Cylinder material: Aluminum alloy (hard anodized)
- Piston rod: SUS304 stainless steel
- Seal material: NBR (nitrile rubber)
- Weight: 0.45kg ±3%
- Dimensions: 125mm(L) × 50mm(W) × 42mm(H)
- Protection rating: IP40 (dust protected)
- Lubrication: Pre-lubricated (use ISO VG32 hydraulic oil)
Compact rotary clamping cylinder combining linear motion with 90° rotation, featuring dual anti-rotation guide rods for enhanced stability. The precision-ground piston rod with wear-resistant coating ensures 500km+ service life. Requires 5μm filtered air and regular lubrication every 3 months under continuous operation.
- Automated fixture positioning in CNC machining centers
- Workpiece flipping mechanisms in assembly lines
- Pallet locking systems in FMS (Flexible Manufacturing Systems)
- PCB handling robots for component insertion
- Medical device assembly tooling
Installation note:
Mount using M4 screws with 30mm center distance. Allow 5mm clearance
for rotation path. Align air ports vertically upward to prevent
condensation accumulation. Break-in period: 50 cycles at 0.3 MPa
before full-pressure operation.
| Property | Property Value |
|---|---|
| sku | QCKR12X10SM |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Direction Code | Right-hand |
