Airtac QCKR Rotary Clamping Cylinder QCKR12X20SM
$43.02
Regular price
$50.52
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
QCKR12X20SM
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Designed for welding environments, the piston rod undergoes QPQ treatment, providing enhanced resistance to weld spatter compared to hard chrome-plated surfaces;
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
Installation guidelines:
Maintain 0.5mm minimum clearance between clamping surface and workpiece.
Use locking compound (LOCTITE 243 recommended) on mounting screws.
Cycle 3-5 times without load after installation to distribute lubrication.
Critical note:
Avoid side-load forces exceeding 5N during operation.
For vertical downward clamping applications, install mechanical stopper as secondary safety.
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Series Rotary Clamping Cylinder QCKR12X20SM Technical Details
- Model: QCKR12X20SM
- Bore size: 12mm
- Stroke: 20mm
- Rotation angle: 90°±5° (clockwise/counter-clockwise selectable)
- Operating pressure: 0.15–0.8 MPa
- Clamping force: 22N @0.4MPa (calculated value)
- Torque output: 0.25N·m @0.4MPa
- Mounting type: M5 through-hole base mounting
- Operation method: Single-acting spring return
- Body material: Anodized aluminum alloy
- Piston rod: Stainless steel (SUS304)
- Seal material: HNBR (high-temperature nitrile)
- Temperature range: -10℃ to 80℃ (dry air required below 0℃)
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil if re-lubrication needed)
- Protection rating: IP40 (IP67 available with optional bellows)
- Port size: M5x0.8 (dual ports for simultaneous rotation/clamping)
- Weight: 0.45kg ±3%
- Dimensions: 82mm(L) × 34mm(W) × 34mm(H) (excluding mounting accessories)
- Total length (extended): 102mm (base to rod end)
Compact rotary clamping cylinder combining 90° rotation with vertical clamping motion through dual pneumatic circuits. Features anti-rotation guide pins for precise angular positioning and shock-absorbing rubber pads for noise reduction (75dB max). Requires 5μm filtered air with 40% relative humidity maximum.
Industrial Applications:
- PCB board fixturing in SMT assembly lines
- Workpiece positioning in CNC machining centers
- End-effector tool switching in collaborative robots
- Optical lens alignment systems
- Semiconductor wafer handling automation
- Medical device component assembly stations
Installation guidelines:
Maintain 0.5mm minimum clearance between clamping surface and workpiece.
Use locking compound (LOCTITE 243 recommended) on mounting screws.
Cycle 3-5 times without load after installation to distribute lubrication.
Critical note:
Avoid side-load forces exceeding 5N during operation.
For vertical downward clamping applications, install mechanical stopper as secondary safety.
| Property | Property Value |
|---|---|
| sku | QCKR12X20SM |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Direction Code | Right-hand |
