Airtac QCKR Rotary Clamping Cylinder QCKR12X20SMFB
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR12X20SMFB Specifications
- Model: QCKR12X20SMFB
- Type: Double-acting rotary clamping cylinder with mechanical lock
- Bore size: 12mm
- Stroke: 20mm
- Operating pressure: 0.15–0.95 MPa
- Torque output: 1.2 N·m (at 0.5 MPa)
- Rotation angle: 90° ±5°
- Port size: M5×0.8 (dual ports)
- Mounting type: Side flange with 4×M3 threaded holes
- Body material: Aluminum alloy (anodized finish)
- Piston rod: Stainless steel SUS304
- Seal material: NBR rubber
- Temperature range: -10℃ to 70℃
- Weight: 0.28 kg
- Dimensions:
- Length (retracted): 75mm
- Width (body): 32mm
- Height (with flange): 45mm
- Mounting hole spacing: 20mm × 20mm
- Cushion type: Adjustable rubber buffer
- Protection rating: IP40
Compact rotary clamping cylinder combining linear motion with 90° rotation, featuring integrated mechanical locking for secure positioning. The dual-port design enables precise bidirectional control, while the hardened guide structure ensures minimal wear during repeated operations. Requires filtered air (≤50μm particles) with recommended ISO VG32 hydraulic oil mist lubrication.
- CNC machine tool fixture clamping
- Automated welding jig positioning
- Robotic end-effector part flipping
- PCB assembly press-fit mechanisms
- Optical lens polishing equipment
Installation note:
Maintain 0.5mm minimum clearance between rotating parts and adjacent components.
Lubricate guide rails monthly with lithium-based grease. Avoid side-load forces exceeding 15N.
| Property | Property Value |
|---|---|
| sku | QCKR12X20SMFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Direction Code | Right-hand |
