Airtac QCKR Rotary Clamping Cylinder QCKR16X10SM
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR16X10SM Specifications
- Model: QCKR16X10SM
- Type: Double-acting rotary clamping cylinder
- Bore size: 16mm
- Stroke: 10mm
- Operating pressure: 0.1–0.9 MPa
- Rotation angle: 90° ±5° (automatic reset)
- Mounting style: Side/Flange mounting (M4 threaded holes)
- Port size: M5×0.8 (Rc1/8 adapter optional)
- Cushioning: Adjustable rubber buffer
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 80℃
- Weight: 0.48 kg ±5%
- Dimensions: 90mm(L) × 32mm(W) × 32mm(H) (extended length: 100mm)
- Torque output: 0.8 N·m @0.5 MPa
- Protection rating: IP54 (standard), IP67 optional
Compact 90° rotary clamp cylinder with integrated T-slot for tooling attachment. Features anti-rotation guide pins and precision-ground piston rod (hard chrome plated, 15μm surface roughness). Designed for repetitive positioning accuracy (±0.5° repeatability) in automated processes. Requires ISO 8573-1 class 3 lubricated air (ISO VG32 recommended).
- CNC machine tool workpiece fixturing
- Robotic arm end-effector clamping
- PCB assembly line positioning
- Automated inspection jigs
- Pallet locking in conveyor systems
Installation tips:
Lubricate pivot points every 500,000 cycles using MOBIL DTE 24 or equivalent.
Avoid side loads exceeding 15N during operation. For vertical mounting,
install exhaust mist lubricator (AM320-02 recommended).
| Property | Property Value |
|---|---|
| sku | QCKR16X10SM |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | Right-hand |
