Airtac QCKR Rotary Clamping Cylinder QCKR16X20S
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR16X20S Technical Specifications
- Model: QCKR16X20S
- Type: Rotary clamping cylinder with integrated wedge mechanism
- Bore size: 16mm
- Stroke: 20mm
- Rotation angle: 90°±2°
- Clamping force: 135N @ 0.5MPa
- Holding torque: 1.6N·m
- Operating pressure: 0.15–0.7MPa
- Port thread: M5×0.8 (dual ports)
- Body material: Aluminum alloy (anodized)
- Piston rod: SUS304 stainless steel
- Seal material: NBR + PU hybrid
- Temperature range: -20℃ to 80℃
- Weight: 0.68kg
- Dimensions: 110mm(L) × 40mm(W) × 40mm(H)
- Mounting: Standard M6 threaded holes (4x)
- Protection rating: IP54 (standard), IP67 optional
Compact rotary clamp cylinder combining linear thrust and rotational motion through precision-ground helical guides. Features zero-backlash cam mechanism with self-locking capability. Anti-rotation design maintains orientation during operation. Includes built-in cushioning at both stroke ends with adjustable dampers (factory preset).
- CNC machine tool fixture positioning
- Robotic welding jig locking systems
- Automated assembly line part retention
- Precision grinding machine workholding
- PCB testing equipment component clamping
Installation note:
Requires minimum 0.1μm filtered air supply. Lubricate with ISO VG32 turbine oil
through air line lubricator (oil mist type). Avoid side-load forces exceeding 15N
during operation. Perform manual rotation test before pneumatic connection.
| Property | Property Value |
|---|---|
| sku | QCKR16X20S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | Right-hand |
