Airtac QCKR Rotary Clamping Cylinder QCKR20X10SMFB
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR20X10SMFB Specifications
- Model Code Breakdown: QCKR(Series) 20(Bore) X10(Stroke) S(Structure) M(Mounting) F(Optional) B(Optional)
- Bore Size: 20 mm
- Stroke: 10 mm
- Operating Pressure: 0.1–0.7 MPa
- Action Type: Double-acting with spring return
- Rotation Angle: 90° ±2° (adjustable via stopper)
- Buffer Type: Rubber cushion (both ends)
- Mounting Style: Standard foot mounting (MF suffix)
- Port Thread: 1/8" NPT (G1/8 optional)
- Seal Material: Nitrile Butadiene Rubber (NBR)
- Operating Temperature: -10℃ to +70℃
- Protection Class: IP40 (dust-proof)
- Piston Speed: 50–800 mm/s (lubricated)
- Weight: 0.65 kg ±3% (excluding accessories)
- Dimensions: 80mm(L) × 55mm(W) × 70mm(H) (foot mount included)
- Rod Thread: M6×1.0 external thread
- Repeat Positioning Accuracy: ±0.3 mm
A compact rotary clamping cylinder combining linear thrust with 90° rotation for precision workpiece fixation. Features dual sealing layers and chrome-plated piston rod for corrosion resistance. The integrated T-slot design allows direct mounting of grippers/jaws. Requires 5-40μm filtered air with ISO VG32 lubricator oil (optional oil-free operation).
- CNC machine tool automatic chuck systems
- Robotic welding fixture positioning
- PCB assembly line component retention
- Automotive part transfer mechanisms
- Pharmaceutical packaging rotary indexing
Installation Guidelines:1. Align mounting surface flatness within 0.2mm
2. Maintain 0.5–1.5mm clearance between clamp arm and workpiece
3. Use counterbore screws (M5×0.8 recommended) for base fixation
4. Lubricate pivot points every 2 million cycles
5. Avoid side loads exceeding 15N on rotating shaft
| Property | Property Value |
|---|---|
| sku | QCKR20X10SMFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | Right-hand |
