Airtac QCKR Rotary Clamping Cylinder QCKR20X20SM
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR20X20SM Technical Details
- Model: QCKR20X20SM
- Type: Compact rotary clamping cylinder with mechanical lock
- Bore size: 20mm
- Stroke: 20mm
- Operating pressure: 0.1–0.7 MPa
- Operating temperature: -20℃ to 80℃
- Port size: PT1/8 (G1/8 optional)
- Rotation angle: 90° ±5°
- Clamping force: 220N @0.5MPa
- Body material: Aluminum alloy (anodized)
- Seal material: NBR
- Buffer type: Rubber cushion
- Mounting style: Side-mount with M5 threaded holes
- Weight: 0.82kg ±3%
- Dimensions: 80mm(L) × 40mm(W) × 40mm(H)
- Protection rating: IP54
- Reaction time: ≤0.3s (full rotation)
Precision rotary clamping cylinder featuring integrated mechanical locking for zero-backlash operation. The double-acting design enables 90° rotation with automatic position holding via spring-engaged brake mechanism. Hard chrome-plated piston rod ensures wear resistance in high-cycle applications (up to 1 million cycles). Includes adjustable torque limiter to prevent over-clamping damage.
- CNC machine tool fixture positioning
- Automotive welding jig quick-change systems
- Electronics PCB press-fitting mechanisms
- Packaging machine mold clamping
- Robotic end-effector tool changers
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.3mm minimum clearance between clamp arm and workpiece surface.
Use clean dry air with 5-40μm filtration. For vertical mounting,
install air inlet port downward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | QCKR20X20SM |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | Right-hand |
