Airtac RMS Magnetic Coupling Rodless Cylinder RMS32X130
2. Piston movement transmitted to external slider via magnetic coupling force, eliminating piston rod requirements - features reduced installation space compared to standard cylinders while achieving longer maximum stroke;
3. Integrated adjustable cushioning at both ends with fixed cushioning mechanisms ensures smooth directional changes without impact shock, effectively preventing mechanical damage;
4. Isolation design between piston chamber and slider prevents contaminant ingress, significantly prolongs service life of the cylinder.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMS
AirTAC RMS32X130 Magnetic Coupling Rodless Cylinder Specifications
- Model: RMS32X130
- Type: ISO 15552 compliant rodless cylinder with magnetic coupling
- Bore size: 32 mm
- Stroke: 130 mm (±0.5 mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Max thrust: 245 N at 0.6 MPa
- Piston speed: 50–1000 mm/s (optimal range 100–500 mm/s)
- Ambient temperature: -20℃ to 80℃
- Cushioning: Built-in elastic buffer + external shock absorber option
- Lubrication: Pre-lubricated (ISO VG32 equivalent), maintenance-free for 2000 km travel
- Mounting: Multiple options (side-mount, foot-mount, flange)
- Weight: 2.2 kg (excluding accessories)
- Dimensions: 300mm(L) × 60mm(W) × 50mm(H) (full extension)
- Repeat accuracy: ±0.1 mm
- Protection rating: IP65 (standard), IP67 optional
- Material: Aluminum alloy body, NBR seals, hardened stainless steel guide rail
High-precision rodless cylinder using non-contact magnetic coupling technology, eliminating external leakage risks. Features dual-channel dust wipers and wear compensation system. The carriage integrates T-slot mounting surfaces (per ISO 6432) for flexible tooling attachment. Requires 40μm filtered air with dew point -25℃ below ambient.
- High-speed pick-and-place systems in electronics assembly
- Cleanroom material handling (semiconductor/LCD production)
- Precision coating/spraying equipment
- Cartesian robot X/Y axis drives
- Food packaging lines with frequent washdowns
Installation note:
Align guide rail within 0.05mm/m straightness tolerance. For vertical mounting,
use counterbalance valves. Relubricate every 5000 km using AirTAC L-AN68
equivalent grease via built-in nipples.
| Property | Property Value |
|---|---|
| sku | RMS32X130 |
| Mounting Type | Without Mounting Accessories |
| Safety Holding Force N | Stroke: 560mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°F Speed Range: 50-400 mm/s |
| Port Size | PT1/8 |
| Cushion Type | Fixed Cushion |
| Bore Diameter | <32 mm> |
| Stroke | 130mm |
