Airtac RMS Magnetic Coupling Rodless Cylinder RMS32X150
$251.47
Regular price
$258.97
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
RMS32X150
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Magnetic coupling rodless cylinder with no mechanical connection between piston and slider, offering excellent sealing performance;
2. Piston movement transmitted to external slider via magnetic coupling force, eliminating piston rod requirements - features reduced installation space compared to standard cylinders while achieving longer maximum stroke;
3. Integrated adjustable cushioning at both ends with fixed cushioning mechanisms ensures smooth directional changes without impact shock, effectively preventing mechanical damage;
4. Isolation design between piston chamber and slider prevents contaminant ingress, significantly prolongs service life of the cylinder.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMS
Installation note:
Maintain parallel alignment within 0.1mm/m during mounting. Use only non-magnetic mounting hardware
to prevent interference with magnetic coupling. Lubricate guide rails with ISO VG32 hydraulic oil
every 1,000km of travel.
Critical parameters:
2. Piston movement transmitted to external slider via magnetic coupling force, eliminating piston rod requirements - features reduced installation space compared to standard cylinders while achieving longer maximum stroke;
3. Integrated adjustable cushioning at both ends with fixed cushioning mechanisms ensures smooth directional changes without impact shock, effectively preventing mechanical damage;
4. Isolation design between piston chamber and slider prevents contaminant ingress, significantly prolongs service life of the cylinder.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMS
AirTAC RMS32X150 Magnetic Coupling Rodless Cylinder Specifications
- Model: RMS32X150
- Type: Magnetic coupling rodless cylinder (non-rotating design)
- Bore size: 32mm
- Stroke length: 150mm (customizable up to 2000mm)
- Operating pressure: 0.05–0.9 MPa
- Cushioning type: Adjustable air cushion at both ends
- Ambient temperature: -20℃ to 80℃
- Maximum speed: 0.1–1.5 m/s
- Mounting style: Standard profile with multiple T-slots (M6 threaded)
- Seal material: Heat-resistant polyurethane (NBR optional)
- Repeat positioning accuracy: ±0.2mm
- Weight: 2.8 kg (with standard mounting brackets)
- Dimensions: 300mm(L) × 52mm(W) × 42mm(H) (body only at zero stroke)
- Total length (stroke included): 300mm + 150mm stroke = 450mm
- Port size: G1/8 (NPT1/8 optional)
- Lubrication: Pre-lubricated (DOP-free)
- Protection rating: IP54 (standard), IP67 with optional wiper seals
High-precision rodless cylinder using magnetic coupling technology to eliminate external leakage points. Features dual-piston design with integrated linear guide for enhanced moment resistance. The stainless steel band seal ensures contamination resistance in harsh environments. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3 air quality.
Typical Applications:
- High-speed pick-and-place systems in electronics assembly
- Cleanroom automation for semiconductor handling
- Precision coating/spraying equipment
- Vertical lift mechanisms in packaging lines
- Automated optical inspection (AOI) machines
- Battery production line material transfer
Installation note:
Maintain parallel alignment within 0.1mm/m during mounting. Use only non-magnetic mounting hardware
to prevent interference with magnetic coupling. Lubricate guide rails with ISO VG32 hydraulic oil
every 1,000km of travel.
Critical parameters:
- Maximum side load: 45N at mid-stroke
- Magnetic field safety distance: 50mm from sensitive electronics
- Do NOT use in explosive atmospheres (non-ATEX version)
| Property | Property Value |
|---|---|
| sku | RMS32X150 |
| Mounting Type | Without Mounting Accessories |
| Safety Holding Force N | Stroke: 560mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°F Speed Range: 50-400 mm/s |
| Port Size | PT1/8 |
| Cushion Type | Fixed Cushion |
| Bore Diameter | <32 mm> |
| Stroke | 150mm |
