Airtac RMS Magnetic Coupling Rodless Cylinder RMS32X300
$268.22
Regular price
$275.72
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
RMS32X300
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Magnetic coupling rodless cylinder with no mechanical connection between piston and slider, offering excellent sealing performance;
2. Piston movement transmitted to external slider via magnetic coupling force, eliminating piston rod requirements - features reduced installation space compared to standard cylinders while achieving longer maximum stroke;
3. Integrated adjustable cushioning at both ends with fixed cushioning mechanisms ensures smooth directional changes without impact shock, effectively preventing mechanical damage;
4. Isolation design between piston chamber and slider prevents contaminant ingress, significantly prolongs service life of the cylinder.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMS
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting.
Lubricate with ISO VG32 hydraulic oil during initial setup.
Avoid side loads exceeding 15N. For vertical installations,
use counterbalance valves (sold separately).
2. Piston movement transmitted to external slider via magnetic coupling force, eliminating piston rod requirements - features reduced installation space compared to standard cylinders while achieving longer maximum stroke;
3. Integrated adjustable cushioning at both ends with fixed cushioning mechanisms ensures smooth directional changes without impact shock, effectively preventing mechanical damage;
4. Isolation design between piston chamber and slider prevents contaminant ingress, significantly prolongs service life of the cylinder.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMS
AirTAC RMS32X300 Magnetic Coupling Rodless Cylinder Specifications
- Model: RMS32X300
- Type: ISO 15552 compliant rodless cylinder with magnetic coupling
- Bore size: 32mm
- Stroke: 300mm (±1mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Medium temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Repeat positioning accuracy: ±0.5mm
- Max theoretical thrust: 201N @0.5MPa
- Seal material: NBR + special wear-resistant ring
- Slider material: Aluminum alloy with hard anodizing
- Protection rating: IP54 (standard), IP67 (optional)
- Weight: 3.5kg (without accessories)
- Dimensions: 422mm(L) × 60mm(W) × 82mm(H)
- Mounting options: Female thread (M6×1.0) or through-hole Ø6.6mm
High-precision rodless cylinder utilizing non-contact magnetic coupling technology, eliminating external seals for zero leakage. Features dual anti-rotation guides and integrated T-slot for accessory mounting. Requires 5μm filtered air with ISO 8573-1:2010 class 4.4.3 purity.
Typical Applications:
- High-speed pick-and-place systems (electronics assembly)
- Cleanroom material handling (pharmaceutical production)
- Precision coating/spraying equipment
- Automated optical inspection (AOI) machines
- Palletizing robots with lateral movement
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting.
Lubricate with ISO VG32 hydraulic oil during initial setup.
Avoid side loads exceeding 15N. For vertical installations,
use counterbalance valves (sold separately).
| Property | Property Value |
|---|---|
| sku | RMS32X300 |
| Mounting Type | Without Mounting Accessories |
| Safety Holding Force N | Stroke: 560mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°F Speed Range: 50-400 mm/s |
| Port Size | PT1/8 |
| Cushion Type | Fixed Cushion |
| Bore Diameter | <32 mm> |
| Stroke | 300mm |
