Airtac RMSF Magnetic Coupling Rodless Cylinder RMSF20X700
2、Piston motion is transmitted to external slider through magnetic coupling force, achieving compact installation footprint compared to standard cylinders while delivering extended stroke lengths;
3、Integrated adjustable cushioning at both ends with fixed buffer devices enables smooth directional switching without impact shocks, effectively preventing mechanical wear;
4、Isolated piston chamber and slider configuration creates contamination-resistant structure, blocking dust ingress to significantly enhance operational lifespan.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMSF
AirTAC RMSF20X700 Magnetic Coupling Rodless Cylinder Specifications
- Model: RMSF20X700
- Bore size: Ø20mm
- Stroke: 700mm
- Operating pressure: 0.05–0.9 MPa
- Max thrust: 63N (at 0.63MPa)
- Max speed: 500–1000 mm/s (cushioning required)
- Temperature range: -20℃ to 80℃
- Coupling type: External magnetic system (IP67 rated)
- Seal material: NBR + PU combination
- End cushioning: Adjustable pneumatic
- Mounting: Dual-axis alignment slots (M4×0.7 threads)
- Weight: 2.85 kg (including carriage)
- Dimensions: 750mm(L) × 40mm(W) × 50mm(H)
- Repeat positioning accuracy: ±0.5mm
- Lubrication: Pre-lubed (Oil mist lubrication recommended)
High-precision rodless cylinder with zero-leakage magnetic coupling technology, featuring a non-contact sliding mechanism that eliminates seal wear. The anodized aluminum body with chrome-plated piston rod ensures corrosion resistance in humid environments. Integrated shock absorbers allow smooth deceleration at stroke ends.
- Cleanroom automation systems (semiconductor handling)
- Vertical lift mechanisms in packaging lines
- Precision glass panel transfer robots
- High-cycle CNC machine part ejectors
- Pharmaceutical blister packaging machines
Installation tip:
Maintain ≤0.2mm/m alignment tolerance during mounting. Use M4×12 stainless steel screws (3.5N·m torque max).
For full-stroke applications, allow 20mm extra space beyond nominal dimensions for thermal expansion.
| Property | Property Value |
|---|---|
| sku | RMSF20X700 |
| Mounting Type | Without Mounting Accessories |
| Safety Holding Force N | Stroke 220mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°F Speed Range: 50-400 mm/s |
| Port Size | PT1/8 |
| Bore Diameter | <20mm> |
| Stroke | 700mm |
