Airtac RMSF Magnetic Coupling Rodless Cylinder RMSF32X2800
2、Piston motion is transmitted to external slider through magnetic coupling force, achieving compact installation footprint compared to standard cylinders while delivering extended stroke lengths;
3、Integrated adjustable cushioning at both ends with fixed buffer devices enables smooth directional switching without impact shocks, effectively preventing mechanical wear;
4、Isolated piston chamber and slider configuration creates contamination-resistant structure, blocking dust ingress to significantly enhance operational lifespan.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMSF
AirTAC RMSF32X2800 Magnetic Coupling Rodless Cylinder Specifications
- Model: RMSF32X2800
- Type: Magnetic coupling rodless cylinder (non-rotating design)
- Bore size: 32 mm
- Stroke length: 2800 mm
- Operating pressure: 0.1–0.8 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to 80℃
- Seal material: NBR/PU composite
- Port size: M5x0.8 (standard), G1/8 optional
- Mounting style: T-slot groove (15mm width) with multiple mounting brackets
- Repeat positioning accuracy: ±0.5 mm
- Max speed: 2000 mm/s
- Protection rating: IP54 (standard wiper seal)
- Weight: 9.8 kg (including rail)
- Dimensions: 3100mm(L) × 80mm(W) × 50mm(H)
High-precision long-stroke rodless cylinder using magnetic coupling technology to eliminate external seals. Features dual anti-rotation guides for stable linear motion and integrated T-slot for flexible mounting. Ideal for clean environments due to zero external particle generation. Requires 5μm filtered air and monthly lubrication cycle.
- PCB handling in electronics assembly lines
- Pallet transfer systems in logistics automation
- Glass panel positioning in solar module production
- Long-span inspection camera carriers
- Automated warehouse retrieval arms
Installation note:
Requires intermediate support brackets every 1500mm for full-stroke operation.
Magnetic slider position must be calibrated after installation using factory-provided alignment tool.
| Property | Property Value |
|---|---|
| sku | RMSF32X2800 |
| Mounting Type | Without Mounting Accessories |
| Safety Holding Force N | Stroke: 560mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°F Speed Range: 50-400 mm/s |
| Port Size | PT1/8 |
| Bore Diameter | <32 mm> |
| Stroke | 2800MM |
