Airtac RMSF Magnetic Coupling Rodless Cylinder RMSF32X300
$268.22
Regular price
$275.72
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
RMSF32X300
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Magnetically coupled rodless cylinder design eliminates mechanical linkage between piston and slider, ensuring superior sealing performance;
2、Piston motion is transmitted to external slider through magnetic coupling force, achieving compact installation footprint compared to standard cylinders while delivering extended stroke lengths;
3、Integrated adjustable cushioning at both ends with fixed buffer devices enables smooth directional switching without impact shocks, effectively preventing mechanical wear;
4、Isolated piston chamber and slider configuration creates contamination-resistant structure, blocking dust ingress to significantly enhance operational lifespan.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMSF
Installation notes:
Maintain ≤0.2mm/m alignment tolerance between cylinder and guide rails.
Use only non-magnetic mounting brackets. Lubricate slider monthly with ISO VG32 turbine oil.
Avoid lateral forces exceeding 50N on the carriage.
2、Piston motion is transmitted to external slider through magnetic coupling force, achieving compact installation footprint compared to standard cylinders while delivering extended stroke lengths;
3、Integrated adjustable cushioning at both ends with fixed buffer devices enables smooth directional switching without impact shocks, effectively preventing mechanical wear;
4、Isolated piston chamber and slider configuration creates contamination-resistant structure, blocking dust ingress to significantly enhance operational lifespan.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMSF
AirTAC RMSF32X300 Magnetic Coupling Rodless Cylinder Specifications
- Model: RMSF32X300
- Type: ISO 15552 compliant rodless cylinder with magnetic coupling
- Bore size: 32mm (1-1/4")
- Stroke: 300mm (±1mm tolerance)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Max thrust: 256N at 0.6MPa (piston area 8.04cm²)
- Cushioning: Adjustable pneumatic cushioning (both ends)
- Mounting: Multiple options - C1 (side lugs), C4 (front flange), C6 (rear flange)
- Piston seal material: HNBR with wear-resistant coating
- Slider material: Hard-anodized aluminum alloy
- Temperature range: -20℃ to +80℃ (non-freezing)
- Max speed: 0.1–1.5 m/s (optimal range 0.3–0.8 m/s)
- Weight: Approximately 3.2kg (without accessories)
- Dimensions: 400mm(L) × 54mm(W) × 48mm(H) (at mid-stroke position)
- Magnetic coupling force: ≥180N (slider separation force)
- Repeat positioning accuracy: ±0.2mm
- Port size: M5×0.8 (standard), G1/8 optional
- Protection rating: IP54 (standard), IP67 with optional wiper seals
High-precision rodless cylinder using non-contact magnetic coupling technology, eliminating external leakage risks. Features dual-channel dustproof design with integrated scraper seals. The T-slot mounting surface (per ISO 6432) enables flexible accessory integration. Requires 5μm filtered compressed air with oil mist lubrication recommended.
Typical Applications:
- High-speed pick-and-place systems in electronics assembly
- Cleanroom material handling (semiconductor/LCD production)
- Precision coating/spraying equipment
- Palletizing robot end-effector positioning
- Medical device actuator systems
Installation notes:
Maintain ≤0.2mm/m alignment tolerance between cylinder and guide rails.
Use only non-magnetic mounting brackets. Lubricate slider monthly with ISO VG32 turbine oil.
Avoid lateral forces exceeding 50N on the carriage.
| Property | Property Value |
|---|---|
| sku | RMSF32X300 |
| Mounting Type | Without Mounting Accessories |
| Safety Holding Force N | Stroke: 560mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°F Speed Range: 50-400 mm/s |
| Port Size | PT1/8 |
| Bore Diameter | <32 mm> |
| Stroke | 300mm |
