Airtac RMSF Magnetic Coupling Rodless Cylinder RMSF32X350LB
2、Piston motion is transmitted to external slider through magnetic coupling force, achieving compact installation footprint compared to standard cylinders while delivering extended stroke lengths;
3、Integrated adjustable cushioning at both ends with fixed buffer devices enables smooth directional switching without impact shocks, effectively preventing mechanical wear;
4、Isolated piston chamber and slider configuration creates contamination-resistant structure, blocking dust ingress to significantly enhance operational lifespan.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMSF
AirTAC RMSF32X350LB Magnetic Coupling Rodless Cylinder Specifications
- Model: RMSF32X350LB
- Type: Magnetic coupling rodless cylinder (non-rotating)
- Bore size: 32mm
- Stroke: 350mm (±1.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Max thrust: 153N at 0.5MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning: Built-in rubber buffers (both ends)
- Mounting: T-slot base with M6 threaded holes
- Port size: Rc1/8 (G1/8 optional)
- Coupling force: ≥90N
- Seal material: Polyurethane (NBR optional)
- Weight: 2.65kg ±3%
- Dimensions: 450mm(L) × 42mm(W) × 42mm(H)
- Repeat accuracy: ±0.2mm
- Max speed: 1,000mm/s
- Protection rating: IP54 (standard wipers)
High-precision rodless cylinder utilizing magnetic coupling technology for zero leakage and dust-sensitive environments. Features dual piston seals and chromium-plated inner tube for smooth operation. The LB variant includes enhanced lateral load capacity with dual guide rails integrated into the carriage.
- Cleanroom material handling systems
- Precision CNC tool changers
- Pharmaceutical packaging lines
- Lithium battery production equipment
- Glass panel transfer mechanisms
Installation note:
Requires periodic lubrication (ISO VG32 hydraulic oil recommended).
Maintain 0.5mm minimum clearance between magnetic slider and ferrous materials.
For vertical mounting, use anti-drop safety brackets (sold separately).
| Property | Property Value |
|---|---|
| sku | RMSF32X350LB |
| Mounting Type | Foot Mount Bracket |
| Safety Holding Force N | Stroke: 560mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°F Speed Range: 50-400 mm/s |
| Port Size | PT1/8 |
| Bore Diameter | <32 mm> |
| Stroke | 350mm |
