Airtac RMSF Magnetic Coupling Rodless Cylinder RMSF32X400
$279.85
Regular price
$287.35
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
RMSF32X400
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Magnetically coupled rodless cylinder design eliminates mechanical linkage between piston and slider, ensuring superior sealing performance;
2、Piston motion is transmitted to external slider through magnetic coupling force, achieving compact installation footprint compared to standard cylinders while delivering extended stroke lengths;
3、Integrated adjustable cushioning at both ends with fixed buffer devices enables smooth directional switching without impact shocks, effectively preventing mechanical wear;
4、Isolated piston chamber and slider configuration creates contamination-resistant structure, blocking dust ingress to significantly enhance operational lifespan.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMSF
Installation note:
Maintain 0.05mm/m alignment tolerance during rail mounting. Use anti-vibration pads
when operating above 0.5 m/s. Lubricate guide rail weekly in high-cycle applications (>500 cycles/day).
Critical:
Avoid lateral forces exceeding 150N. Magnetic coupling requires minimum 2mm
clearance from ferrous materials. Use only with certified AirTAC magnetic sensors.
2、Piston motion is transmitted to external slider through magnetic coupling force, achieving compact installation footprint compared to standard cylinders while delivering extended stroke lengths;
3、Integrated adjustable cushioning at both ends with fixed buffer devices enables smooth directional switching without impact shocks, effectively preventing mechanical wear;
4、Isolated piston chamber and slider configuration creates contamination-resistant structure, blocking dust ingress to significantly enhance operational lifespan.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMSF
AirTAC RMSF32X400 Magnetic Coupling Rodless Cylinder Specifications
- Model: RMSF32X400
- Type: Magnetic coupling rodless cylinder (non-rotating)
- Bore size: 32mm
- Stroke length: 400mm
- Operating pressure: 0.1–0.8 MPa
- Cushion type: Adjustable elastic buffer
- Mounting style: Horizontal/Vertical/Custom (optional brackets)
- Position detection: Built-in magnet for sensor mounting
- Material: Aluminum alloy cylinder tube, stainless steel guide rail
- Temperature range: -20℃ to 80℃
- Seal material: NBR/PU (optional)
- Protection rating: IP65 (standard), IP67 (optional)
- Weight: 3.5kg (excluding mounting accessories)
- Dimensions: 582mm(L) × 50mm(W) × 72mm(H) (stroke-dependent length)
- Max speed: 0.1–1.5 m/s
- Lubrication: Pre-lubricated (recommended relubrication every 500km travel)
High-precision rodless actuator combining magnetic coupling technology with linear guide rails, eliminating external seals for leak-free operation. Features zero maintenance sliding surfaces and symmetrical load capacity (±10% variation tolerance). Requires 5μm filtered air with ISO 8573-1:2010 class 3.4.3 purity standards.
Typical Applications:
- High-speed pick-and-place systems in electronics assembly
- Precision material handling in cleanroom environments
- Automated packaging line pusher mechanisms
- Plastic injection molding machine ejectors
- Solar panel production conveyor systems
Installation note:
Maintain 0.05mm/m alignment tolerance during rail mounting. Use anti-vibration pads
when operating above 0.5 m/s. Lubricate guide rail weekly in high-cycle applications (>500 cycles/day).
Critical:
Avoid lateral forces exceeding 150N. Magnetic coupling requires minimum 2mm
clearance from ferrous materials. Use only with certified AirTAC magnetic sensors.
| Property | Property Value |
|---|---|
| sku | RMSF32X400 |
| Mounting Type | Without Mounting Accessories |
| Safety Holding Force N | Stroke: 560mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°F Speed Range: 50-400 mm/s |
| Port Size | PT1/8 |
| Bore Diameter | <32 mm> |
| Stroke | <400mm> |
