Airtac SAI100 Standard Air Cylinder SAI100AX110S
The AirTAC Airtac SAI100 Standard Air Cylinder SAI100AX110S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø100mm bore and 110mm stroke, G1/2 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ100 mm
- Stroke110 mm
- Port sizeG1/2
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SAI100 Standard Air Cylinder SAI100AX110S
The AirTAC SAI100X110-S is a double-acting ISO 15552 profile cylinder offering a robust 5497 N push force at 0.7 MPa. Its 110 mm stroke is well-suited for medium-travel material handling and clamping tasks. As a genuine AirTAC component, it ensures reliable performance in demanding industrial environments.
This specific configuration includes a SUS420J2 stainless steel rod for enhanced corrosion resistance. The -S suffix indicates an integrated magnet, allowing seamless operation with CMSE or DMSE reed switches fitted into the dual sensor grooves on the extruded aluminum barrel.
Airtac SAI100 Standard Air Cylinder SAI100AX110S Technical Specifications
| Model | Airtac SAI100 Standard Air Cylinder SAI100AX110S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø100 mm |
| Stroke | 110 mm |
| Acting type | Double acting |
| Port size | G1/2 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI100 Standard Air Cylinder SAI100AX110S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 100 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI100 Standard Air Cylinder SAI100AX110S Is Used
Automotive Parts Clamping
Provides the high clamping force needed to secure heavy automotive castings during machining operations.
Pallet Diversion
Actuates heavy-duty diverters on high-throughput packaging conveyors with reliable speed.
Press Ejection
Ejects formed metal parts from hydraulic presses, utilizing the 110 mm stroke for rapid removal.
Is the Airtac SAI100 Standard Air Cylinder SAI100AX110S the Right Cylinder?
For applications requiring slightly less force, the 80 mm bore provides 3518 N at 0.7 MPa, while stepping up to the 125 mm bore yields 8590 N. Since this 110 mm stroke is under 300 mm, side-load stress on the rod bearing is minimal. However, if the application requires holding a load vertically without continuous air pressure, the cushion cannot act as a brake; consider the SAIL locking variant or an external pilot-operated check valve. This model features a PT G1/2 port, M20x1.5 rod thread, and is dimensionally interchangeable with other ISO 15552 profile cylinders.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI100 Standard Air Cylinder SAI100AX110S FAQ
At an operating pressure of 0.7 MPa, the SAI100X110-S delivers a push force of 5497 N and a pull force of 3681 N.
Yes, the SAI100X110-S is a profile cylinder built to ISO 15552 dimensional standards, making it a drop-in replacement for other ISO 15552 cylinders of the same bore and stroke.
