Airtac SAI100 Standard Air Cylinder SAI100AX130S
The AirTAC Airtac SAI100 Standard Air Cylinder SAI100AX130S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø100mm bore and 130mm stroke, G1/2 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ100 mm
- Stroke130 mm
- Port sizeG1/2
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SAI100 Standard Air Cylinder SAI100AX130S
The AirTAC SAI100X130-S is a double-acting ISO 15552 profile cylinder engineered for heavy-duty automation. It delivers a robust push force of 3927 N and a pull force of 3681 N at 0.5 MPa. The 130 mm stroke is optimal for mid-range clamping and heavy lifting tasks. This extruded aluminum barrel design omits tie-rods for a clean exterior.
This specific configuration includes a magnet for proximity sensing via CMSE or DMSE switches mounted in the dual sensor grooves. It is built with a SUS420J2 stainless steel piston rod (material code A) for superior corrosion resistance. Ports feature PT tapered threads, and adjustable air cushions at both ends manage deceleration effectively.
Airtac SAI100 Standard Air Cylinder SAI100AX130S Technical Specifications
| Model | Airtac SAI100 Standard Air Cylinder SAI100AX130S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø100 mm |
| Stroke | 130 mm |
| Acting type | Double acting |
| Port size | G1/2 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI100 Standard Air Cylinder SAI100AX130S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 100 | Bore size in mm. |
| ×130 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI100 Standard Air Cylinder SAI100AX130S Is Used
Heavy-Duty Stamping
Provides the necessary 3927 N thrust at 0.5 MPa for securely pressing bearings and bushings into heavy housings.
Pallet Diverting
Utilizes the 130 mm stroke to push heavy pallets onto secondary packaging lines with reliable force.
Automated Clamping
Holds large metal or wood workpieces stationary during CNC machining or aggressive cutting operations.
Is the Airtac SAI100 Standard Air Cylinder SAI100AX130S the Right Cylinder?
Selecting this 100 mm bore over the smaller 80 mm bore (2513 N push at 0.5 MPa) is necessary when your application requires high thrust without maximizing the supply pressure. Conversely, if the 3927 N output exceeds your requirement, stepping down saves energy and footprint. The 130 mm stroke is compact enough to avoid severe rod-bearing bending, but any lateral load should still be managed with an external guide.
For a true ISO 15552 drop-in replacement, match the 100 mm bore, 130 mm stroke, G1/2 port, and the required mounting accessory (such as an FA flange or TC trunnion). Because this is a standard double-acting cylinder, it will not hold a load if air pressure is lost. If your system needs static position holding during an air failure, specify the SAIL lock or BSAI clamp-lock variant instead.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI100 Standard Air Cylinder SAI100AX130S FAQ
At 0.5 MPa, the SAI100X130-S generates a push force of 3927 N and a pull force of 3681 N. At 0.7 MPa, the push force increases to 5497 N.
Yes, this SAI profile cylinder is dimensionally interchangeable per ISO 15552. You can drop it in to replace other ISO 15552 cylinders with a 100 mm bore, 130 mm stroke, and G1/2 porting.
