Airtac SAI100 Standard Air Cylinder SAI100AX145S
$196.10
Regular price
$203.60
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAI100AX145S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SAI100 Standard Cylinder Series (ISO15552 compliant, formerly ISO6431)
1. Features specially profiled bidirectional sealing rings with integrated oil reservoir design, ensuring compact dimensions and optimized lubrication.
2. Reinforced cross-section aluminum alloy tube eliminates tie rods, enhancing corrosion resistance. Integrated sensor mounting groove enables tool-free installation of proximity sensors.
3. Adjustable cushioning mechanism provides smooth deceleration throughout stroke termination.
4. Multiple bore sizes and mounting accessories available for diverse industrial automation applications.
5. High-temperature resistant sealing materials (operating range: 0℃ to 150℃) ensure reliable performance in elevated temperature environments.
Category: Standard Cylinders | Brand: AirTAC | Series: SAI100
Installation notes:
1. Maintain 0.5mm minimum clearance between rod end and load during alignment
2. Use locknuts (not included) with M20 rod thread for secure load connection
3. For vertical mounting, install speed controller on lower port to prevent piston slam
4. Recommended air filtration: 5μm with auto-drain function
1. Features specially profiled bidirectional sealing rings with integrated oil reservoir design, ensuring compact dimensions and optimized lubrication.
2. Reinforced cross-section aluminum alloy tube eliminates tie rods, enhancing corrosion resistance. Integrated sensor mounting groove enables tool-free installation of proximity sensors.
3. Adjustable cushioning mechanism provides smooth deceleration throughout stroke termination.
4. Multiple bore sizes and mounting accessories available for diverse industrial automation applications.
5. High-temperature resistant sealing materials (operating range: 0℃ to 150℃) ensure reliable performance in elevated temperature environments.
Category: Standard Cylinders | Brand: AirTAC | Series: SAI100
AirTAC SAI100AX145S Standard Cylinder Specifications
- Model: SAI100AX145S
- Type: ISO 15552 compliant double-acting pneumatic cylinder
- Bore size: 100 mm
- Stroke: 145 mm (adjustable cushioning)
- Operating pressure: 0.1–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning type: Adjustable air cushion (both ends)
- Mounting style: Basic front flange (ISO 15552 MF1), multiple mounting options available
- Port size: G3/8 (ISO 228/1 standard)
- Piston rod thread: M20×1.5 external
- Material:
- Tube: Hard anodized aluminum alloy
- Piston rod: Chrome-plated stainless steel (SUS304)
- End caps: Aluminum alloy with oxidation resistance
- Seal material: High-grade NBR (Nitrile Butadiene Rubber)
- Protection rating: IP65 (standard wiper design)
- Speed range: 50–800 mm/s (lubricated operation)
- Lubrication: Pre-lubricated (maintenance-free for 5,000 km)
- Weight: 5.8 kg (including mounting accessories)
- Dimensions:
- Total length: 328 mm (at mid-stroke position)
- Width (mounting flange): 112 mm
- Height (cylinder diameter): 108 mm
The SAI100AX145S features a reinforced piston rod guide system with integrated wear compensation, designed for high-cycle industrial applications. Its corrosion-resistant construction and precision-machined components ensure smooth operation even under 24/7 continuous duty cycles. The cylinder comes with built-in magnetic sensor slots (T-slot design) for position feedback devices.
Typical Applications:
- Automotive assembly line clamping mechanisms
- Heavy-duty press machine actuation
- Plastic injection molding ejector systems
- Industrial automation material handling
- Packaging machinery pusher assemblies
Installation notes:1. Maintain 0.5mm minimum clearance between rod end and load during alignment
2. Use locknuts (not included) with M20 rod thread for secure load connection
3. For vertical mounting, install speed controller on lower port to prevent piston slam
4. Recommended air filtration: 5μm with auto-drain function
| Property | Property Value |
|---|---|
| sku | SAI100AX145S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Piston Rod Material | SUS420J2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 145mm |
