Airtac SAI160 Standard Cylinder SAI160AX1000
The AirTAC SAI160 Standard Cylinder SAI160AX1000 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 1000mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke1000 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI160 Standard Cylinder SAI160AX1000
The AirTAC SAI160X1000 is a robust double-acting ISO 15552 profile cylinder engineered for heavy-duty motion. It features a 160mm bore and a 1000mm stroke, generating 10053 N of push force and 9425 N of pull force at 0.5 MPa. This model is equipped with a SUS420J2 stainless steel rod (code A) for superior corrosion resistance and utilizes PT tapered port threads.
Designed for demanding environments, the extruded aluminum barrel includes sensor grooves on both sides for direct mounting of CMSE or DMSE switches. While this specific configuration omits the magnet option, the cylinder retains adjustable air cushions at both ends (50 mm cushion length) to manage high kinetic energy. For operations requiring bidirectional clamping or fail-safe holding, consider the related BSAI clamp-lock series.
Airtac SAI160 Standard Cylinder SAI160AX1000 Technical Specifications
| Model | Airtac SAI160 Standard Cylinder SAI160AX1000 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10053 N | 9425 N |
| 0.7 MPa | 14074 N | — |
| Max (@1.0 MPa) | 2050 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI160 Standard Cylinder SAI160AX1000
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI160 Standard Cylinder SAI160AX1000 Is Used
Heavy Stamping
Provides the high thrust necessary for metal forming, punching, and heavy-duty stamping presses.
Large Material Handling
Ideal for actuating massive conveyor diverters or moving heavy pallets over long 1000mm distances.
Automotive Assembly
Handles large structural components or robotic welding fixtures requiring substantial reach and force.
Is the Airtac SAI160 Standard Cylinder SAI160AX1000 the Right Cylinder?
Selecting this 160mm bore over the smaller 125mm bore yields a significant force jump, stepping up from 6136 N to 10053 N at 0.5 MPa. If your application requires less thrust, the 100mm bore offers 3927 N. Because this model features a 1000mm stroke, the extended rod is highly susceptible to bending under side loads; always utilize external guide rails or a guided carriage to prevent premature rod-bearing wear.
As a dimensionally interchangeable ISO 15552 profile cylinder, this unit serves as a direct replacement for other ISO 15552 standard cylinders. Match your mounting hardware (such as CA clevis or TC trunnion) and ensure your pneumatic supply is filtered to 40 um. Note that a standard SAI cylinder will drift if air pressure is lost; use an external rod lock for vertical load-holding applications.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI160 Standard Cylinder SAI160AX1000 FAQ
At 0.5 MPa, this 160mm bore cylinder provides 10053 N of push force and 9425 N of pull force. At the maximum operating pressure of 1.0 MPa, the theoretical push force reaches 2050 kgf.
Yes, the SAI160X1000 is a true ISO 15552 profile cylinder, making it dimensionally interchangeable with other ISO 15552 cylinders of the same bore and stroke. Ensure your mounting accessories and PT port connections match.
