Airtac SAI160 Standard Cylinder SAI160AX1000S
The AirTAC SAI160 Standard Cylinder SAI160AX1000S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 1000mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke1000 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI160 Standard Cylinder SAI160AX1000S
The AirTAC SAI160X1000-S is a double-acting profile cylinder built to strict ISO 15552 dimensional standards, ensuring direct compatibility with other ISO 15552 interface machines. Operating at 0.15-1.0 MPa, it generates 10053 N of push force at 0.5 MPa, making it a robust choice for heavy-duty actuation.
This specific configuration includes a SUS420J2 stainless steel rod for superior corrosion resistance and a built-in magnet (-S) for precise position sensing with CMSE or DMSE switches along the dual sensor grooves. It utilizes PT tapered port threads and adjustable air cushions at both ends to manage kinetic energy.
Airtac SAI160 Standard Cylinder SAI160AX1000S Technical Specifications
| Model | Airtac SAI160 Standard Cylinder SAI160AX1000S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10053 N | 9425 N |
| 0.7 MPa | 14074 N | — |
| Max (@1.0 MPa) | 2050 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI160 Standard Cylinder SAI160AX1000S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI160 Standard Cylinder SAI160AX1000S Is Used
Heavy Stamping
Provides the robust 10053 N push force required to operate large mechanical stamping presses and heavy forming dies.
Pallet Diversion
Handles the high kinetic energy and long 1000 mm reach needed to divert heavy loaded pallets across wide conveyor belts.
Automated Assembly
Drives large automotive component fixtures and heavy chassis positioning arms over extended machine envelopes.
Is the Airtac SAI160 Standard Cylinder SAI160AX1000S the Right Cylinder?
Selecting this 160 mm bore over the smaller 125 mm bore yields a significant force jump from 6136 N to 10053 N at 0.5 MPa. If your application requires less force, stepping down reduces air consumption. Because this model features a 1000 mm stroke, side loads pose a severe risk of bending the rod and prematurely wearing the guide bearing. Implement an external linear guide rail or use a guided cylinder to prevent binding.
This unit is dimensionally interchangeable with any true ISO 15552 cylinder of the same bore and stroke. Ensure your setup accommodates the G3/4 port size and PT thread type. If the machinery must hold a load vertically without continuous air pressure, the standard SAI will drift downward; deploy the SAIL locking variant or an external pilot-operated check valve for safety.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI160 Standard Cylinder SAI160AX1000S FAQ
At a 0.5 MPa operating pressure, this 160 mm bore cylinder generates a push force of 10053 N. At 0.7 MPa, the push force increases to 14074 N.
Yes, the SAI series is a genuine ISO 15552 profile cylinder, making its mounting dimensions fully interchangeable with other ISO 15552 cylinders of the same bore size, regardless of brand.
