Airtac SAI160 Standard Cylinder SAI160AX105S
The AirTAC SAI160 Standard Cylinder SAI160AX105S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 105mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke105 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI160 Standard Cylinder SAI160AX105S
The AirTAC SAI160X105-S is a double-acting ISO 15552 profile cylinder engineered for heavy-duty applications. It provides a substantial push force of 10053 N at 0.5 MPa, making it well-suited for high-mass automation tasks requiring a 105 mm stroke.
This specific configuration includes a SUS420J2 stainless steel rod for enhanced corrosion resistance and PT tapered port threads. The -S option equips the barrel with a magnet for seamless integration with CMSE and DMSE sensor switches along the dual grooves.
Airtac SAI160 Standard Cylinder SAI160AX105S Technical Specifications
| Model | Airtac SAI160 Standard Cylinder SAI160AX105S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 105 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10053 N | 9425 N |
| 0.7 MPa | 14074 N | — |
| Max (@1.0 MPa) | 2050 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI160 Standard Cylinder SAI160AX105S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×105 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI160 Standard Cylinder SAI160AX105S Is Used
Heavy Metal Stamping
Provides the robust 10053 N push force required to operate large mechanical stamping presses and heavy-duty forming equipment.
Injection Molding Ejection
Delivers reliable and powerful ejection strokes for large industrial injection molded parts within harsh manufacturing environments.
Automotive Assembly Jigs
Drives substantial clamping and positioning jigs for automotive chassis components, utilizing its SUS420J2 rod for durability.
Is the Airtac SAI160 Standard Cylinder SAI160AX105S the Right Cylinder?
If you need slightly less force, stepping down to a 125 mm bore yields 6136 N at 0.5 MPa, whereas moving up to a 200 mm bore provides 15708 N. Because this 105 mm stroke is relatively short for the large bore, side-load stress on the rod bearing is minimal compared to longer strokes.
For applications requiring position holding without sustained air pressure, note that the standard adjustable air cushions only decelerate the piston at stroke ends. You must employ an external pilot-operated check valve or select the SAIL lock variant to prevent drifting under load. This unit is dimensionally interchangeable per ISO 15552, utilizing a G3/4 port and standard mounting accessories.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI160 Standard Cylinder SAI160AX105S FAQ
At an operating pressure of 0.5 MPa, the SAI160X105-S cylinder exerts a push force of 10053 N and a pull force of 9425 N.
Yes, the SAI160X105-S is dimensionally interchangeable per ISO 15552, allowing it to serve as a direct replacement for other standard profile cylinders with matching dimensions.
