Airtac SAI160 Standard Cylinder SAI160AX10S
The AirTAC SAI160 Standard Cylinder SAI160AX10S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 10mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke10 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI160 Standard Cylinder SAI160AX10S
The AirTAC SAI160X10-S is a double-acting ISO 15552 profile cylinder engineered for heavy-duty operations requiring very short linear movements. Delivering a substantial 10053 N of push force at 0.5 MPa, this 160 mm bore unit is purpose-built for high-impact pressing and clamping. The 10 mm stroke provides rapid, precise displacement in compact machinery setups.
As an -S designated variant, this model includes an integrated magnet for non-contact position sensing using CMSE or DMSE switches along the dual sensor grooves. Following the authoritative configuration, the piston rod is constructed from SUS420J2 stainless steel (code A) for superior corrosion resistance, and the fluid ports feature a PT tapered thread design for robust, leak-free pneumatic connections.
Airtac SAI160 Standard Cylinder SAI160AX10S Technical Specifications
| Model | Airtac SAI160 Standard Cylinder SAI160AX10S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10053 N | 9425 N |
| 0.7 MPa | 14074 N | — |
| Max (@1.0 MPa) | 2050 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI160 Standard Cylinder SAI160AX10S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI160 Standard Cylinder SAI160AX10S Is Used
Heavy-Duty Stamping
Generates 10053 N of thrust at 0.5 MPa to drive short 10 mm stamping and marking operations in automated metal fabrication lines.
Industrial Riveting
Provides the high impact force necessary for setting large rivets in structural steel assembly, utilizing the 160 mm bore capacity.
Component Seating
Excels at pressing heavy bearings or bushings into housings, relying on the SUS420J2 stainless steel rod for durability in harsh environments.
Is the Airtac SAI160 Standard Cylinder SAI160AX10S the Right Cylinder?
Select this 160 mm bore cylinder when an application demands extreme force over a minimal 10 mm travel distance, such as stamping or riveting. If the application requires slightly less force and a smaller physical footprint, consider the 100 mm bore option, which provides 3927 N of push force at 0.5 MPa. For operations needing even greater thrust than 10053 N, the 200 mm bore offers 15708 N at the same pressure.
Because the standard SAI is a double-acting pneumatic actuator, it cannot hold a load in place if air pressure is lost or the control valve is centered; the rod will drift. If static holding is mandatory for safety in this high-force regime, specify the SAIL (air-released lock) or BSAI (bidirectional clamp-lock) variant instead. Being a true ISO 15552 profile cylinder, this model is dimensionally interchangeable with other ISO 15552 cylinders, utilizing a PT G3/4 port, standard mounting accessories (like FA flange or TC trunnion), and the built-in magnet for sensor integration.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI160 Standard Cylinder SAI160AX10S FAQ
At an operating pressure of 0.5 MPa, this 160 mm bore cylinder generates a push force of 10053 N and a pull force of 9425 N. The maximum theoretical force at 1.0 MPa is 2050 kgf.
Yes, the SAI160X10-S is a genuine ISO 15552 profile cylinder, making its mounting interface and envelope dimensions interchangeable with other ISO 15552 cylinders. You can easily drop it into existing setups using standard FA, FB, or TC mounting accessories.
