Airtac SAI160 Standard Cylinder SAI160AX115S
2. Special-shaped bidirectional piston sealing structure with compact dimensions and integrated oil retention features
3. H-beam reinforced aluminum tube without tie rods ensures superior corrosion resistance, featuring integrated sensor mounting grooves for rapid installation
4. Adjustable cushioning mechanism with smooth operation characteristics
5. Multiple configurations and mounting accessories available for customized solutions
6. High-temperature resistant sealing materials enable stable operation in 0°C to 150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI160
AirTAC SAI160AX115S Standard Cylinder Specifications
- Model: SAI160AX115S
- Bore size: 160mm
- Stroke: 115mm
- Operating pressure: 0.1–0.9 MPa
- Cushion type: Adjustable air cushion (both ends)
- Port size: G3/8 (NPT1/4 optional)
- Mounting style: Basic type (front/rear flange or foot mounting available)
- Temperature range: -20℃ to 80℃
- Piston material: Die-cast aluminum alloy with hard anodizing
- Rod material: Chrome-plated carbon steel (Cr-Mo)
- Seal material: NBR (nitrile rubber)
- Protection rating: IP65 (standard wiper design)
- Weight: 6.5kg ±2% (without accessories)
- Dimensions: 350mm(L) × 160mm(W) × 160mm(H) (extended length)
- Retract length: 235mm (minimum installation space)
- Theoretical thrust: 11,304N @0.5MPa (push side)
- Max piston speed: 500–700 mm/s (with cushion)
High-performance ISO15552 compliant cylinder optimized for heavy-duty industrial applications. Features corrosion-resistant construction with double-sealed rod bearing for extended service life. The precision-machined inner tube (RAL2 roughness ≤0.2μm) ensures smooth operation even under side load conditions. Requires ISO 8573-1:2010 [4:4:4] class compressed air.
- Automated palletizing systems in logistics centers
- Die-casting machine ejection mechanisms
- Steel mill roller adjustment assemblies
- Plastic injection molding machine clamping units
- Automotive welding fixture positioning
Installation guidelines:
Maintain 0.05–0.15mm clearance between rod end and load connection for thermal expansion.
Lubricate with ISO VG32 hydraulic oil during assembly. Avoid angular misalignment exceeding ±2°.
| Property | Property Value |
|---|---|
| sku | SAI160AX115S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
