Airtac SAI160 Standard Cylinder SAI160AX130S
The AirTAC SAI160 Standard Cylinder SAI160AX130S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 130mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke130 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI160 Standard Cylinder SAI160AX130S
The AirTAC SAI160X130-S is a double-acting ISO 15552 profile cylinder engineered for heavy-duty automation. Delivering a robust 14074 N of push force at 0.7 MPa, this 160 mm bore unit is built to move substantial loads across its 130 mm stroke. The extruded aluminum barrel eliminates tie-rods, providing a clean profile that drops directly into standardized ISO 15552 mounting footprints.
This specific configuration includes a SUS420J2 stainless steel piston rod (material code A) for enhanced corrosion resistance compared to standard carbon steel. Equipped with a magnet (-S), it supports direct mounting of CMSE and DMSE series sensor switches along the dual grooves machined into the barrel. For environments requiring elevated temperatures, the standard TPU seals can be swapped for Viton (H) or NBR (N) options.
Airtac SAI160 Standard Cylinder SAI160AX130S Technical Specifications
| Model | Airtac SAI160 Standard Cylinder SAI160AX130S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 130 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10053 N | 9425 N |
| 0.7 MPa | 14074 N | — |
| Max (@1.0 MPa) | 2050 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI160 Standard Cylinder SAI160AX130S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×130 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI160 Standard Cylinder SAI160AX130S Is Used
Heavy Metal Forming
Provides the high clamping force required to hold thick steel plates securely in place during stamping and heavy press operations.
Large Assembly Presses
Drives robust pressing actions for seating large bearings or mating heavy industrial components with precise 130 mm travel.
Pallet Diverting
Actuates heavy-duty diverters and lifting gates on high-capacity conveyor lines handling dense or oversized product loads.
Is the Airtac SAI160 Standard Cylinder SAI160AX130S the Right Cylinder?
Selecting this 160 mm bore makes sense when 100 mm cylinders lack the necessary thrust, pushing output from 5497 N up to 14074 N at 0.7 MPa. If 14074 N is excessive for your application, stepping down to an 80 mm bore yields 3518 N, optimizing air consumption. Because this model features a 130 mm stroke, side-load stress on the rod bearing is minimal, but external guides should still be used if the load is not perfectly axial.
If your application requires the piston to maintain its position during a loss of air pressure, the standard SAI cylinder will drift and cannot hold the load. In such scenarios, specify the SAIL variant with an air-released lock, or the BSAI bidirectional clamp-lock cylinder. This SAI160X130-S features PT tapered port threads and a G3/4 port size.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI160 Standard Cylinder SAI160AX130S FAQ
At an operating pressure of 0.7 MPa, this 160 mm bore cylinder generates 14074 N of push force and 9425 N of pull force. At 0.5 MPa, the push force is 10053 N.
Yes, the SAI160X130-S is dimensionally interchangeable per ISO 15552. You can drop it into existing mounts matching the ISO 15552 interface, though you must verify the G3/4 port and M36x2 rod thread compatibility.
