Airtac SAI160 Standard Cylinder SAI160AX145S
The AirTAC SAI160 Standard Cylinder SAI160AX145S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 145mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke145 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI160 Standard Cylinder SAI160AX145S
The AirTAC SAI160X145-S is a double-acting ISO 15552 profile cylinder engineered for heavy-duty operations, delivering a robust push force of 10053 N at 0.5 MPa. Its 145 mm stroke is ideal for high-thrust pressing, lifting, and clamping tasks. The extruded aluminum barrel design omits traditional tie rods, providing a clean exterior while maintaining strict dimensional interchangeability with other ISO 15552 profile cylinders.
This specific configuration includes a SUS420J2 stainless steel rod (option A) for superior corrosion and scratch resistance in harsh environments. It is equipped with a magnetic piston (-S) for seamless integration with CMSE or DMSE position sensors, and utilizes PT tapered port threads to ensure a positive, leak-free pneumatic connection.
Airtac SAI160 Standard Cylinder SAI160AX145S Technical Specifications
| Model | Airtac SAI160 Standard Cylinder SAI160AX145S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 145 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10053 N | 9425 N |
| 0.7 MPa | 14074 N | — |
| Max (@1.0 MPa) | 2050 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI160 Standard Cylinder SAI160AX145S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×145 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI160 Standard Cylinder SAI160AX145S Is Used
Heavy Metal Stamping
Provides the 10053 N force required to securely stamp and form thick metal components in automated fabrication lines.
Automotive Assembly Presses
Drives large jigs and fixtures on vehicle assembly lines, utilizing the 145 mm stroke to seat heavy chassis components.
Pallet Load Handling
Lifts and positions fully loaded pallets in distribution centers, where the stainless steel rod withstands abrasive dust.
Is the Airtac SAI160 Standard Cylinder SAI160AX145S the Right Cylinder?
If your application requires slightly less force, stepping down to the 125 bore yields 6136 N at 0.5 MPa, whereas moving up to the massive 200 bore provides 15708 N. Because this is a double-acting cylinder, it relies on continuous air pressure to hold its position; if air is lost, the piston will drift. For dead-end holding without live pressure, consider the SAIL (air-released lock) or BSAI (bidirectional clamp-lock) variants. To match this unit, specify a 160 mm bore, 145 mm stroke, PT G3/4 port, and your preferred mounting accessory such as a CA clevis or LB foot. The -S magnet is already included for switch mounting.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI160 Standard Cylinder SAI160AX145S FAQ
At 0.5 MPa operating pressure, the push force is 10053 N and the pull force is 9425 N. At 0.7 MPa, the push force increases to 14074 N.
Yes, the SAI160X145-S is dimensionally interchangeable per ISO 15552 mounting interfaces, allowing it to serve as a direct replacement for other standard profile cylinders in this bore size.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
