Airtac SAI160 Standard Cylinder SAI160AX155S
2. Special-shaped bidirectional piston sealing structure with compact dimensions and integrated oil retention features
3. H-beam reinforced aluminum tube without tie rods ensures superior corrosion resistance, featuring integrated sensor mounting grooves for rapid installation
4. Adjustable cushioning mechanism with smooth operation characteristics
5. Multiple configurations and mounting accessories available for customized solutions
6. High-temperature resistant sealing materials enable stable operation in 0°C to 150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI160
AirTAC SAI160AX155S Standard Cylinder Specifications
- Model: SAI160AX155S
- Series: ISO 15552 Standard (160mm bore size)
- Type: Double-acting pneumatic cylinder
- Bore size: 160mm
- Stroke: 155mm (customizable up to 2000mm)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Cushion type: Adjustable air cushion (both ends)
- Port size: G3/4 (NPT 3/4 optional)
- Mounting style: Basic foot mounting (ISO 15552-MBF)
- Ambient temperature: -20℃ to 80℃
- Piston rod material: Hard chrome-plated 45# steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile) standard, optional FKM/Viton
- Protection rating: IP65 (wipers included)
- Weight: 9.8kg ±2% (without accessories)
- Dimensions:
- Length: 365mm (min. retracted length)
- Width: 180mm (mounting base width)
- Height: 200mm (including rod end)
High-torque industrial cylinder designed for heavy-duty linear motion applications. Features precision honed tube with 20μm Ra surface finish and wear-resistant guide rings. The magnetic piston version (SAI160AX155S-M) enables position sensing compatibility. Requires 40μm filtered air with ISO VG32 lubrication (optional oil-free operation).
- Automotive production line clamping fixtures
- Die-casting machine ejector systems
- Steel mill roller positioning mechanisms
- Plastic injection molding machine core pulls
- Warehouse automated stacking systems
Installation guidelines:
Allow 20mm clearance for cushion adjustment screws. For vertical mounting,
use locknut (AN8) on piston rod thread. Lubricate through air ports during
initial commissioning (30-50 duty cycles recommended).
| Property | Property Value |
|---|---|
| sku | SAI160AX155S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
