Airtac SAI200 Standard Cylinder SAI200AX10
The AirTAC Airtac SAI200 Standard Cylinder SAI200AX10 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø200mm bore and 10mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ200 mm
- Stroke10 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
About the Airtac SAI200 Standard Cylinder SAI200AX10
The AirTAC SAI200X10 is a double-acting ISO 15552 profile cylinder featuring a highly customized 10mm stroke. Engineered for extreme thrust, it generates 15708N of push force and 15080N of pull force at just 0.5 MPa. This ultra-short stroke is tailored for high-impact clamping or pressing operations where space is strictly limited.
This specific configuration utilizes a SUS420J2 stainless steel piston rod (material code A) for superior corrosion resistance in humid or mildly chemically washed environments. It features PT tapered port threads and lacks a standard magnet. For operations requiring position holding without live air pressure, consider the SAIL (air-released lock) or BSAI (bidirectional clamp-lock) variants.
Airtac SAI200 Standard Cylinder SAI200AX10 Technical Specifications
| Model | Airtac SAI200 Standard Cylinder SAI200AX10 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø200 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (@1.0 MPa) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI200 Standard Cylinder SAI200AX10
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI200 Standard Cylinder SAI200AX10 Is Used
Heavy-Duty Stamping
Ideal for short-stroke, high-force stamping and forming tasks in metal fabrication, delivering up to 21991N at 0.7 MPa.
Industrial Clamping
Provides immense holding power for securing large molds or heavy workpieces during machining, utilizing a robust 40mm diameter rod.
Press Fit Assembly
Perfect for driving large bearings or pins into heavy housings where a compact 10mm stroke prevents over-travel.
Is the Airtac SAI200 Standard Cylinder SAI200AX10 the Right Cylinder?
Selecting this 200mm bore model is appropriate when the application demands maximum thrust, as stepping down to a 160mm bore reduces the 0.5 MPa push force to 10053N. Because this 10mm stroke is a non-standard, made-to-order configuration, expect extended lead times. The extruded aluminum profile barrel integrates seamlessly with ISO 15552 mounting dimensions.
For short-stroke pressing tasks, ensure the mounting accessory (such as an FA flange or LB foot) perfectly aligns the load to prevent side-load damage to the rod bearing. Since the standard SAI lacks a locking mechanism, the piston will drift if air pressure is lost; do not rely on the adjustable air cushions for load holding. Add an external rod lock or pilot-operated check valve if fail-safe positioning is mandatory.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI200 Standard Cylinder SAI200AX10 FAQ
At 0.5 MPa operating pressure, the SAI200X10 delivers 15708N of push force and 15080N of pull force. At 0.7 MPa, the push force increases to 21991N.
Yes, the SAI200X10 features a standard ISO 15552 mounting interface and extruded aluminum profile barrel, making it dimensionally interchangeable with other ISO 15552 profile cylinders of the same bore size.
