Airtac SAI200 Standard Cylinder SAI200AX1000S
The AirTAC Airtac SAI200 Standard Cylinder SAI200AX1000S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø200mm bore and 1000mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ200 mm
- Stroke1000 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
About the Airtac SAI200 Standard Cylinder SAI200AX1000S
The AirTAC SAI200X1000-S is a double-acting ISO 15552 profile cylinder engineered for heavy-duty automation. It delivers a substantial push force of 15708 N and a pull force of 15080 N at 0.5 MPa, making it well-suited for moving massive loads over its 1000 mm stroke. The extruded aluminum barrel design omits tie-rods, providing a clean profile that drops directly into standard ISO 15552 mounting interfaces.
This specific configuration includes a magnet for proximity sensing (-S), allowing seamless integration with CMSE or DMSE switches housed in the barrel's dual sensor grooves. It is built with an SUS420J2 stainless steel piston rod (material code A) for enhanced corrosion resistance, and utilizes tapered PT ports for reliable pneumatic connections.
Airtac SAI200 Standard Cylinder SAI200AX1000S Technical Specifications
| Model | Airtac SAI200 Standard Cylinder SAI200AX1000S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø200 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (@1.0 MPa) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI200 Standard Cylinder SAI200AX1000S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI200 Standard Cylinder SAI200AX1000S Is Used
Heavy Machinery Forming
Provides the robust 15708 N thrust at 0.5 MPa required to actuate large forming presses and heavy industrial machinery over a 1000 mm travel distance.
Automated Assembly Line Actuators
Drives massive structural components or chassis frames on automotive assembly lines, utilizing the dual sensor grooves and integrated magnet for precise end-position verification.
Large Material Handling
Shifts heavy palletized goods or bulk materials in automated warehousing systems, where the SUS420J2 stainless steel rod offers reliable resistance against harsh environmental factors.
Is the Airtac SAI200 Standard Cylinder SAI200AX1000S the Right Cylinder?
Selecting this 200 mm bore cylinder is appropriate when application thrust requirements exceed the 10053 N push force available from the 160 mm bore variant at 0.5 MPa. Operating speed ranges from 30-500 mm/s. Because this model features a 1000 mm stroke, the extended rod is highly susceptible to bending under side loads; utilizing an external guide rail or a guided cylinder mechanism is strongly recommended to prevent premature rod-bearing wear.
As a standard double-acting actuator, this cylinder relies on continuous air pressure to hold its position. If your machinery requires the load to remain securely locked during an emergency stop or pressure loss, integrate the SAIL variant with an air-released lock or utilize the BSAI bidirectional clamp-lock series. For direct replacements, match the 200 mm bore, 1000 mm stroke, PT port thread, and appropriate mounting accessory like the TC trunnion.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI200 Standard Cylinder SAI200AX1000S FAQ
At an operating pressure of 0.5 MPa, the SAI200X1000-S generates a push force of 15708 N and a pull force of 15080 N. At 0.7 MPa, the push force increases to 21991 N.
Yes, the SAI200X1000-S is dimensionally interchangeable per ISO 15552. You can drop it into existing machinery by matching the 200 mm bore, 1000 mm stroke, PT port thread, and standard mounting accessories, provided the physical envelope matches.
