Airtac SAI200 Standard Cylinder SAI200AX130S
The AirTAC Airtac SAI200 Standard Cylinder SAI200AX130S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø200mm bore and 130mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ200 mm
- Stroke130 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
About the Airtac SAI200 Standard Cylinder SAI200AX130S
The AirTAC SAI200X130-S is a double-acting ISO 15552 profile cylinder built for heavy-duty automation. It delivers 15708 N of push force and 15080 N of pull force at 0.5 MPa, making it suitable for moving massive loads. The 130 mm stroke provides targeted linear displacement for large-scale pressing or positioning tasks.
This specific configuration includes a SUS420J2 stainless steel rod for enhanced durability against corrosion and surface wear. It is equipped with a -S magnet for use with CMSE and DMSE sensor switches, which mount directly into the dual-side extruded aluminum barrel grooves. The unit features PT tapered port threads and adjustable air cushions at both ends to manage deceleration.
Airtac SAI200 Standard Cylinder SAI200AX130S Technical Specifications
| Model | Airtac SAI200 Standard Cylinder SAI200AX130S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø200 mm |
| Stroke | 130 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (@1.0 MPa) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI200 Standard Cylinder SAI200AX130S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×130 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI200 Standard Cylinder SAI200AX130S Is Used
Heavy Metal Forming
Provides the 15708 N push force required for stamping, bending, and forming thick metal sheets in primary metalworking lines.
Large Press Tending
Actuates heavy-duty doors, clamps, and material ejection systems on large industrial mechanical and hydraulic presses.
Automotive Assembly Jigs
Positions heavy chassis or powertrain components on automotive lines, utilizing the integrated magnet for end-of-stroke confirmation.
Is the Airtac SAI200 Standard Cylinder SAI200AX130S the Right Cylinder?
At 200 mm bore, this cylinder sits at the top of the standard SAI force range, offering 15708 N at 0.5 MPa. If your application requires less force, stepping down to a 160 mm bore provides 10053 N, which may reduce air consumption and footprint. The 130 mm stroke is short enough to avoid significant rod-bearing bending, but always ensure the load is axially aligned to prevent side-load wear.
As a true ISO 15552 profile cylinder, it is dimensionally interchangeable with other ISO 15552 cylinders for direct drop-in replacements. Remember that standard double-acting cylinders do not hold position when air pressure is lost; for fail-safe load holding, consider the SAIL or BSAI variants. This model matches a 200 mm bore, 130 mm stroke, PT port, and includes a magnet.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI200 Standard Cylinder SAI200AX130S FAQ
At 0.5 MPa, the SAI200X130-S generates a push force of 15708 N and a pull force of 15080 N. At 0.7 MPa, the push force increases to 21991 N.
Yes, the SAI200X130-S is a genuine ISO 15552 profile cylinder, meaning its mounting dimensions are standardized for direct interchangeability with other ISO 15552 compliant cylinders from various manufacturers.
