Airtac SAI32 Standard Cylinder SAI32AX1000
The AirTAC SAI32 Standard Cylinder SAI32AX1000 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø32mm bore and 1000mm stroke, G1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke1000 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI32 Standard Cylinder SAI32AX1000
The AirTAC SAI32X1000 is a double-acting ISO 15552 profile-barrel standard cylinder featuring a 32mm bore and a 1000mm stroke. Because this stroke exceeds the standard 500mm limit for this bore, it is manufactured as a non-standard, made-to-order item. It generates 402N of push force at 0.5 MPa and 563N at 0.7 MPa.
This model features a SUS420J2 stainless steel rod (material code A) for enhanced resistance to corrosion and wear. It uses PT tapered port threads and lacks a magnet, meaning it cannot directly host CMSE or DMSE sensor switches without modification. For applications requiring position holding without air pressure, the SAIL variant is recommended.
Airtac SAI32 Standard Cylinder SAI32AX1000 Technical Specifications
| Model | Airtac SAI32 Standard Cylinder SAI32AX1000 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI32 Standard Cylinder SAI32AX1000
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI32 Standard Cylinder SAI32AX1000 Is Used
Long-Reach Pushing
Ideal for extending actuators across wide machine spans to push light materials, utilizing the 1000mm stroke while keeping the compact 32mm bore footprint.
Material Diversion
Actuates long-throw diverter arms on conveyor lines, providing 563N of push force at 0.7 MPa to reliably shift products between lanes.
Vertical Elevation
Raises light loads to elevated platforms in storage systems, requiring external guide rails to support the rod over the 1-meter extension.
Is the Airtac SAI32 Standard Cylinder SAI32AX1000 the Right Cylinder?
Selecting this 1000mm stroke model requires careful attention to mechanical stability. At 1000mm, the unsupported rod is highly susceptible to bending under side loads. To prevent premature rod-bearing wear and cylinder damage, use an external guide rail or switch to a guided cylinder. If your force requirements are lower, stepping down is not an option below 32mm, but stepping up to a 40mm bore (528N pull at 0.5 MPa) offers a stiffer 16mm rod.
This non-standard configuration includes a PT tapered port thread, a 12mm rod with an M10x1.25 thread, and 27mm adjustable air cushions at both ends. It provides a direct replacement for other ISO 15552 profile cylinders. Remember that standard SAI cylinders drift when air pressure is removed; use an external check valve or the SAIL lock variant for secure load holding.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI32 Standard Cylinder SAI32AX1000 FAQ
The SAI32X1000 provides a push force of 402N at 0.5 MPa and 563N at 0.7 MPa, with a theoretical maximum force of 82 kgf at 1.0 MPa.
Yes, the SAI32X1000 is a genuine ISO 15552 profile cylinder, making it dimensionally interchangeable with other ISO 15552 standard cylinders of the same bore and stroke.
