Airtac SAI32 Standard Cylinder SAI32AX1000S
2. Asymmetrical bidirectional sealing structure for piston with integrated oil reservoir, ensuring compact dimensions;
3. Mesh-reinforced aluminum tube construction without tie rods, excellent corrosion resistance. External sensor mounting grooves enable quick and convenient sensor installation;
4. Smooth cushioning adjustment mechanism;
5. Multiple cylinder configurations and mounting accessories available for customer customization;
6. High-temperature resistant sealing materials compatible with operating temperature range of 0~150℃.
Category: Standard Cylinders , Brand: AirTAC , Series: SAI32
AirTAC SAI32AX1000S Standard Cylinder Specifications
- Series: SAI Standard ISO Cylinder
- Bore size: Ø32mm
- Stroke: 1000mm (adjustable stroke available)
- Operating pressure: 0.05–1.0 MPa
- Medium temperature: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Port size: G1/8 (NPT1/8 optional)
- Mounting type: Basic foot mounting (MF1), optional flange/bracket
- Piston material: Aluminum alloy with hard anodization
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal type: NBR standard (FKM available for high temp)
- Weight: 4.8kg ±2% (without accessories)
- Dimensions: 1116mm(L) × 64mm(W) × 64mm(H)
- Rod thread: M14×1.5 (external)
- Max theoretical thrust: 246N @0.6MPa
- ISO standard: 6432
High-precision industrial cylinder featuring corrosion-resistant construction and ultra-long stroke capability. The twin piston guide design ensures stable operation at maximum extension. Includes wear-resistant rod bushing and anti-rotation mechanism for precision alignment. Requires 40μm filtered air with ISO VG32 lubricator (optional oil-free operation).
- Automated palletizing systems (box pushing/positioning)
- Paper processing machinery tension control
- Automotive welding fixture positioning
- Plastic injection mold core pulling
- Solar panel production line material handling
Installation note:
Requires intermediate support when stroke exceeds 800mm. Maintain 0.5-1mm alignment tolerance during mounting.
Lubricate rod weekly in high-cycle applications (>500k cycles/month).
| Property | Property Value |
|---|---|
| sku | SAI32AX1000S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Piston Rod Material | SUS420J2 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | <1000mm> |
