Airtac SAI32 Standard Cylinder SAI32AX125S
2. Asymmetrical bidirectional sealing structure for piston with integrated oil reservoir, ensuring compact dimensions;
3. Mesh-reinforced aluminum tube construction without tie rods, excellent corrosion resistance. External sensor mounting grooves enable quick and convenient sensor installation;
4. Smooth cushioning adjustment mechanism;
5. Multiple cylinder configurations and mounting accessories available for customer customization;
6. High-temperature resistant sealing materials compatible with operating temperature range of 0~150℃.
Category: Standard Cylinders , Brand: AirTAC , Series: SAI32
AirTAC SAI32AX125S Standard Cylinder Specifications
- Model: SAI32AX125S (ISO 6432 compliant)
- Bore size: 32 mm
- Stroke: 125 mm (customizable 25-500 mm)
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Adjustable air cushion (both ends)
- Port size: Rc1/8 (G1/8 optional)
- Piston speed: 50–750 mm/s
- Ambient temperature: -20℃ to 80℃
- Mounting type: Basic series (axial foot, front flange, rear flange options)
- Material: Aluminum alloy barrel (SUS304 stainless steel optional)
- Seal material: NBR (HNBR/Viton® available)
- Protection rating: IP65 (standard), IP67 (optional)
- Weight: 1.65 kg (without rod end accessories)
- Dimensions:
- Extended length: 310 mm
- Retracted length: 185 mm
- Body width: 54 mm
- Height with mounting foot: 68 mm
High-precision ISO cylinder featuring dual-piston guidance for minimized lateral deflection. The anodized barrel surface reduces wear resistance by 38% compared to standard models. Integrated magnetic slot (Φ8×2.5 mm) allows for position sensing. Requires ISO 8573-1 class 3 lubricated air (VG32 oil mist recommended).
- Automated material handling systems
- Plastic injection molding ejectors
- CNC machine tool clamping mechanisms
- Food processing conveyor gate actuators
- Pharmaceutical packaging vertical lifts
Installation guidelines:
Align piston rod within 0.5° angular misalignment tolerance. For horizontal mounting exceeding 1m stroke,
support rod end with 70%+ stroke length guide. Lubricate every 5 million cycles under continuous operation.
| Property | Property Value |
|---|---|
| sku | SAI32AX125S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Piston Rod Material | SUS420J2 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
