Airtac SAI50 Standard Cylinder SAI50AX110
The AirTAC SAI50 Standard Cylinder SAI50AX110 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø50mm bore and 110mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ50 mm
- Stroke110 mm
- Port sizeG1/4
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 30 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI50 Standard Cylinder SAI50AX110
The AirTAC SAI50X110 is a double-acting ISO 15552 profile cylinder featuring a 50mm bore and 110mm stroke. It generates 982 N of push force at 0.5 MPa, making it well-suited for medium-duty handling and clamping tasks that require a compact footprint.
This unit is configured with a SUS420J2 stainless steel piston rod (material code A) for enhanced corrosion resistance in humid environments. It uses tapered PT port threads and lacks a magnet; if position detection is needed later, an -S variant with dual-side sensor grooves for CMSE or DMSE switches is required.
Airtac SAI50 Standard Cylinder SAI50AX110 Technical Specifications
| Model | Airtac SAI50 Standard Cylinder SAI50AX110 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø50 mm |
| Stroke | 110 mm |
| Acting type | Double acting |
| Port size | G1/4 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø50mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 825 N |
| 0.7 MPa | 1374 N | — |
| Max (@1.0 MPa) | 200 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI50 Standard Cylinder SAI50AX110
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 50 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI50 Standard Cylinder SAI50AX110 Is Used
Component Clamping
Provides 982 N of push force at 0.5 MPa to secure medium-sized metal components during machining or welding operations.
Package Diverting
Uses the 110mm stroke to push standard cartons off a main conveyor belt onto secondary packaging lines efficiently.
Pallet Positioning
Shifts lightweight pallets or tote bins into precise alignment at automated warehouse workstations without requiring external guides.
Is the Airtac SAI50 Standard Cylinder SAI50AX110 the Right Cylinder?
If 982 N at 0.5 MPa is insufficient for your load, step up to the 63mm bore, which provides 1559 N of push force. For lighter duties, the 40mm bore offers 628 N. Because this is a standard 110mm stroke, side-load stress on the rod bearing is minimal compared to longer strokes.
As a true ISO 15552 profile barrel cylinder, this model is dimensionally interchangeable with other ISO 15552 cylinders. To replicate this exact configuration, specify a 50mm bore, 110mm stroke, PT port threads, SUS420J2 rod material, and no magnet. Note that the standard SAI does not hold loads when air pressure is lost; for position holding without live pressure, consider the SAIL locking variant or an external rod lock.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI50 Standard Cylinder SAI50AX110 FAQ
The SAI50X110 generates 982 N of push force and 825 N of pull force at 0.5 MPa. At 0.7 MPa, the push force increases to 1374 N.
Yes, the SAI50X110 is a genuine ISO 15552 profile cylinder, meaning its mounting interface and envelope dimensions are interchangeable with other ISO 15552 standard cylinders.
