Airtac SAI50 Standard Cylinder SAI50AX145S
The AirTAC SAI50 Standard Cylinder SAI50AX145S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø50mm bore and 145mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ50 mm
- Stroke145 mm
- Port sizeG1/4
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 30 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI50 Standard Cylinder SAI50AX145S
The AirTAC SAI50X145-S is a double-acting ISO 15552 profile cylinder offering a 50mm bore and 145mm stroke. It generates 982N of push force and 825N of pull force at 0.5 MPa, making it well-suited for medium-duty handling tasks.
This specific configuration includes a SUS420J2 stainless steel rod for enhanced corrosion resistance and a built-in magnet for use with CMSE or DMSE sensor switches. The extruded aluminum barrel features sensor grooves on both sides, and the PT tapered port ensures a robust pneumatic connection.
Airtac SAI50 Standard Cylinder SAI50AX145S Technical Specifications
| Model | Airtac SAI50 Standard Cylinder SAI50AX145S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø50 mm |
| Stroke | 145 mm |
| Acting type | Double acting |
| Port size | G1/4 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø50mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 825 N |
| 0.7 MPa | 1374 N | — |
| Max (@1.0 MPa) | 200 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI50 Standard Cylinder SAI50AX145S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 50 | Bore size in mm. |
| ×145 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI50 Standard Cylinder SAI50AX145S Is Used
Material Diversion
Ideal for actuating medium-duty diverter arms on packaging lines, utilizing the 145mm stroke to route products efficiently.
Vertical Lifting
Provides reliable upward push force for lifting tote bins or pallets in automated storage and retrieval systems.
Part Clamping
Holds workpieces securely during machining or assembly operations, taking advantage of the 825N pull force at 0.5 MPa.
Is the Airtac SAI50 Standard Cylinder SAI50AX145S the Right Cylinder?
If your application requires less force, stepping down to a 40mm bore yields 628N at 0.5 MPa; conversely, moving up to a 63mm bore provides 1559N. For this 145mm stroke, side-load stress on the rod bearing is moderate, but external guides are recommended if heavy or off-center loads are present.
As a true ISO 15552 profile cylinder, this model is dimensionally interchangeable with other ISO 15552 cylinders. Remember that the adjustable air cushions only decelerate the piston at stroke ends; they do not hold a load. If position holding without air pressure is needed, consider the SAIL lock variant or an external rod lock.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI50 Standard Cylinder SAI50AX145S FAQ
At a standard operating pressure of 0.5 MPa, this 50mm bore cylinder provides a push force of 982N and a pull force of 825N. At 0.7 MPa, the push force increases to 1374N.
Yes, the SAI50X145-S is a genuine ISO 15552 profile cylinder, meaning its mounting dimensions are standardized for direct replacement compatibility with other ISO 15552 cylinders.
