Airtac SAID100 Double Rod Cylinder SAID100AX210S
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX210S Double Rod Cylinder Specifications
- Model: SAID100AX210S
- Type: ISO 15552 compliant double rod cylinder
- Bore size: 100 mm
- Stroke: 210 mm (±1mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Basic front flange (NF series compatible)
- Port size: G3/8 (NPT1/2 optional)
- Piston rod diameter: 25 mm (chrome-plated steel)
- Temperature range: -20℃ to 80℃
- Seal material: Polyurethane (NBR optional)
- Tube material: Anodized aluminum alloy
- Weight: 5.8 kg (without accessories)
- Dimensions: 594mm(L) × 128mm(W) × 128mm(H)
- Protection rating: IP54 (standard), IP67 (customizable)
- Lubrication: Pre-lubricated (Grease-free operation possible)
High-rigidity double rod cylinder designed for precision linear motion with enhanced moment resistance. Features twin piston rods for symmetrical force distribution and optional magnetic piston for position sensing. The anodized barrel provides corrosion resistance in humid environments, while the chrome-plated rods ensure smooth operation even with side loads.
- Automated palletizing systems requiring dual-direction force
- Precision press-fitting operations in automotive assembly
- Glass cutting machinery with lateral stability demands
- Material testing equipment for balanced load applications
- Plastic injection molding machine ejectors
Installation tip:
Maintain parallel alignment of both rod ends with guided structures.
For strokes over 200mm, recommend using intermediate rod supports every 500mm.
Lubricate rod surfaces weekly in high-cycle applications (>500k cycles/month).
| Property | Property Value |
|---|---|
| sku | SAID100AX210S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | 210mm |
