Airtac SAID100 Double Rod Cylinder SAID100AX220S
$281.71
Regular price
$289.21
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAID100AX220S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
Installation guidelines:
For horizontal mounting, maintain ≤0.1mm/m alignment tolerance.
Lubricate via inlet port using ISO VG32 hydraulic oil (1-2 drops per 1,000 cycles).
Allow 15mm minimum clearance for rod extension.
Critical note:
When used in vertical orientation, install flow control valves on both ports
to prevent piston free-fall. Maximum side load: 350N at mid-stroke.
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX220S Double Rod Cylinder Technical Details
- Model: SAID100AX220S
- Type: ISO 6432 standard double rod cylinder
- Bore size: Ø100 mm
- Stroke: 220 mm (customizable 25-2000mm)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Basic type (MF1) with optional flange/feet mounts
- Port size: G1/2 (NPT1/2 optional)
- Temperature range: -20℃ to 80℃
- Piston rod material: Hard chrome-plated steel (stainless steel optional)
- Tube material: Anodized aluminum alloy
- Seal material: NBR/PU (FDA compliant options available)
- Protection rating: IP65 (standard), IP67 w/wiper upgrade
- Weight: 6.8 kg (dry), 7.1 kg (with standard accessories
- Dimensions:
- Length: 546 mm (220mm stroke)
- Body width: 128 mm
- Height: 112 mm (excluding mounting hardware)
- Rod diameter: Ø25 mm (both rods)
High-rigidity dual piston rod cylinder featuring symmetrical force output and enhanced lateral load capacity. The SAID100 series incorporates a chromium-plated piston rod with multi-layered seal system, achieving ≤0.5 mm/s creep speed at 0.5 MPa. Includes magnetic piston for position sensing compatibility (sensors sold separately).
Industrial Applications:
- Precision press mechanisms in CNC machining centers
- Material clamping systems for semiconductor wafer handling
- Synchronized lifting platforms in automated warehouses
- Web tension control in printing/converting machinery
- Position locking in automotive welding jigs
Installation guidelines:
For horizontal mounting, maintain ≤0.1mm/m alignment tolerance.
Lubricate via inlet port using ISO VG32 hydraulic oil (1-2 drops per 1,000 cycles).
Allow 15mm minimum clearance for rod extension.
Critical note:
When used in vertical orientation, install flow control valves on both ports
to prevent piston free-fall. Maximum side load: 350N at mid-stroke.
| Property | Property Value |
|---|---|
| sku | SAID100AX220S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | 220mm |
