Airtac SAID100 Double Rod Cylinder SAID100AX225S
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX225S Twin Shaft Cylinder Specifications
- Model: SAID100AX225S
- Type: Double rod ISO standard cylinder (Twin axis)
- Bore size: Ø100 mm
- Stroke: 225 mm (adjustable cushion)
- Operating pressure: 0.1–0.9 MPa
- Cushion type: Air cushion adjustable (both ends)
- Mounting style: Square flange (MF12) with front dual rod
- Port size: G1/2 (M16x1.5 optional)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy barrel, hard anodized piston rod
- Seal material: NBR/PU combination
- Weight: 7.5 kg (dry, without accessories)
- Dimensions: 595mm(L) × 128mm(W) × 128mm(H)
- Rod diameter: Ø25mm (dual rods)
- Max thrust: 706 N @0.63MPa
- Piston speed: 50–800 mm/s
- Protection class: IP65 (standard seals)
Industrial-grade twin shaft cylinder designed for precision linear motion requiring enhanced rigidity and moment resistance. Features dual chromium-plated piston rods for balanced load distribution and anti-rotation stability. Integrated magnetic slot (optional) enables position sensing. The through-shaft design allows symmetrical force application in both directions.
- Precision clamping fixtures in CNC machining centers
- Vertical lifting platforms with counterbalance needs
- Glass cutting machinery requiring dual-side force control
- Automated welding jigs with anti-torsion requirements
- Press brake tooling alignment systems
Installation note:
Ensure proper rod alignment using alignment couplers when extending stroke.
Lubricate with ISO VG32 hydraulic oil during initial setup. Maintain minimum
5mm clearance around cylinder body for heat dissipation.
| Property | Property Value |
|---|---|
| sku | SAID100AX225S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | 225mm |
