Airtac SAID100 Double Rod Cylinder SAID100AX230S
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX230S Dual Rod Cylinder Specifications
- Model: SAID100AX230S
- Type: ISO 6432 standard dual rod pneumatic cylinder
- Bore size: 100 mm
- Stroke: 230 mm (adjustable cushioning)
- Rod diameter: 25 mm (both rods)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Cushioning type: Adjustable elastic buffer (both ends)
- Mounting style: MF1 basic front flange with integrated mounting holes
- Port size: G3/8 (NPT1/2 optional)
- Seal material: Polyurethane (PU) with wear-resistant ring
- Weight: 12.8 kg (without accessories)
- Dimensions:
- Body length: 450 mm (excluding rods)
- Total length (stroke extended): 450 + 230×2 = 910 mm
- Width: 120 mm (flange to flange)
- Height: 135 mm (including mounting base)
High-rigidity dual rod cylinder designed for precision alignment applications requiring symmetrical force distribution. Features chromium-plated piston rods with integrated scraper seals to prevent contamination. The twin-rod configuration minimizes rotational torque during operation, making it ideal for vertical installations.
- Automated welding fixture positioning systems
- Precision glass panel handling in LCD manufacturing
- Vertical lifting platforms in automotive assembly lines
- Paper feed mechanisms in heavy-duty printing presses
- Parallel gripper drives for robotic material handling
Installation note:
Maintain 0.05-0.1mm alignment tolerance during mounting.
Requires weekly lubrication (ISO VG32 hydraulic oil recommended)
when used in high-cycle (>500,000 cycles/month) applications.
Magnetic switch slots (T-slot design) are pre-machined on both sides.
| Property | Property Value |
|---|---|
| sku | SAID100AX230S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | <230 mm> |
