Airtac SAID100 Double Rod Cylinder SAID100AX250
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX250 Twin Axis Cylinder Technical Details
- Full model: SAID100AX250
- Series: SAID Twin Rod Compact Cylinder
- Bore size: Ø100mm
- Stroke: 250mm (adjustable within 0-250mm)
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Elastic buffer + adjustable cushion screw
- Port size: 1/4" NPT (G1/4 optional)
- Mounting: Basic type (side fixed mounting holes)
- Piston rod material: Hard-anodized aluminum alloy barrel with chrome-plated alloy steel rods
- Seal material: NBR (Nitrile) standard (Polyurethane available for special orders)
- Temperature range: -20℃ to 80℃
- Protection rating: IP40 (Dust protected)
- Weight: 5.8kg (without accessories)
- Dimensions: 560mm(L) × 150mm(W) × 125mm(H) (Cylinder body only, stroke extended)
High-rigidity twin rod pneumatic cylinder designed for applications requiring exceptional lateral stability and precise linear motion. Features symmetrical dual piston rods that eliminate rotational torque, making it ideal for precision clamping and lifting operations. The through-rod design ensures equal forces in both extension/retraction directions.
- Precision press fitting in automotive assembly lines
- Vertical lifting platforms in material handling systems
- Simultaneous workpiece clamping in CNC machining centers
- Glass panel positioning in photovoltaic module production
- Dual-axis synchronization in automated packaging machinery
Installation guidelines:
Maintain parallel alignment within 0.2mm/m tolerance during mounting.
Use anti-vibration washers when operating above 3Hz cycling frequency.
Lubricate with ISO VG32 hydraulic oil if using non-lubricated air supply.
| Property | Property Value |
|---|---|
| sku | SAID100AX250 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | <250MM> → <250mm> |
