Airtac SAID100 Double Rod Cylinder SAID100AX250S
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX250S Twin Rod Cylinder Technical Details
- Model: SAID100AX250S
- Type: ISO 15552 compliant twin rod cylinder
- Bore size: Ø100mm (±0.1mm tolerance)
- Stroke: 250mm (adjustable cushioning)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Rod diameter: Ø25mm (chrome-plated steel)
- Rod end type: Double clevis with M20x1.5 threads
- Cushioning: Adjustable pneumatic cushion (5mm adjustment range)
- Mounting options: FA-10 front flange, MSQ100 side mount
- Seal material: NBR + polyurethane (temperature-optimized)
- Temperature range: -20℃ to +80℃ (dry air required below 0℃)
- Air port size: G3/8 (ISO 1179-1 standard)
- Weight: 12.3kg (without accessories)
- Dimensions:
- Total length: 580mm (250mm stroke + 330mm base)
- Body diameter: Ø140mm
- Rod center distance: 80mm
- Mounting height: 120mm
- Protection rating: IP65 (rod seals)
- Lubrication: Pre-lubricated (recommended relube interval: 500km)
High-rigidity twin rod cylinder designed for precision alignment applications requiring exceptional lateral load resistance. Features dual chromium-plated piston rods with anti-rotation design, achieving ≤0.05mm/m straightness tolerance. Integrated shock absorbers reduce end-impact noise by 15dB compared to standard models. Compatible with SNS-L100 series magnetic sensors (sold separately).
- Automated welding fixture positioning systems
- Heavy-duty press brake tool changers
- Paper converting machinery guide systems
- Solar panel laminate press actuators
- Automotive wheel alignment test rigs
Installation protocol:
Maintain ≤0.1mm/m parallelism between rods and guide rails. Use torque wrench for mounting bolts (45Nm ±5%).
For vertical installations, install air vents upward and use SA-1000 rod lock accessory (optional).
| Property | Property Value |
|---|---|
| sku | SAID100AX250S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | <250MM> → <250mm> |
