Airtac SAID100 Double Rod Cylinder SAID100AX275
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX275 Dual Rod Cylinder Specifications
- Model: SAID100AX275
- Type: ISO 6432 standard dual rod cylinder
- Bore size: 100mm
- Stroke: 275mm (adjustable cushion)
- Rod type: Double chrome-plated steel rods
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Port size: G3/8 (NPT1/4 optional)
- Seal material: NBR + PU combination
- Temperature range: -20℃ to 80℃
- Mounting: Standard ISO flange/Foot mounts
- Weight: 3.5kg (without accessories)
- Dimensions: 558mm(L) × 100mm(Bore W) × 134mm(H with brackets)
- Rod diameter: 25mm (dual rods)
- Max thrust: 785N @ 0.7MPa
- Piston speed: 50–700mm/s
- Protection rating: IP54 (standard seals)
High-rigidity dual rod cylinder designed for applications requiring exceptional anti-rotation stability and precise linear motion. Features symmetrical force distribution through parallel rods, ideal for vertical installations. The anodized aluminum barrel with hardened end caps ensures durability in high-cycle operations. Includes magnetic piston for position sensing compatibility.
- Vertical lifting mechanisms in material handling
- Precision alignment systems for semiconductor manufacturing
- Clamping fixtures in CNC machining centers
- Packaging machine lid press mechanisms
- Automated welding equipment positioners
Installation note:
Maintain 0.1mm maximum lateral misalignment during mounting. Use flexible couplings when connecting to guided loads. Lubricate rods monthly with ISO VG32 hydraulic oil in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | SAID100AX275 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | 275mm |
