Airtac SAID100 Double Rod Cylinder SAID100AX300
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX300 Twin Rod Cylinder Specifications
- Model: SAID100AX300
- Type: Double rod pneumatic cylinder (ISO 15552 standard)
- Bore size: Ø100 mm
- Stroke: 300 mm (customizable: 25-2000mm)
- Operating pressure: 0.1-1.0 MPa
- Max thrust: 785 N @0.63MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/2 (NPT1/2 optional)
- Mounting: Standard ISO foot & front flange (MF12)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR/PU (FDA compliant options available)
- Temperature range: -20℃ to 80℃
- Weight: 12.5 kg (±3%)
- Dimensions: 675mm(L) × 130mm(W) × 130mm(H)
- Rod diameter: Ø25mm (dual rods)
- Max speed: 0.5-1.5 m/s
- Protection class: IP54 (standard wipers)
Heavy-duty twin rod cylinder designed for precision linear motion requiring enhanced rigidity and moment resistance. Features symmetrical dual piston rods that eliminate rotational torque, with integrated magnet for position sensing. The double rod configuration ensures equal speed/force in both directions, ideal for balanced load applications.
- Automated material handling systems
- Precision press-fit machinery
- Automotive welding fixture positioning
- Paper converting equipment
- Glass panel transfer mechanisms
- Packaging machine clamping units
Installation note:
Ensure proper alignment using precision levels during mounting.
Lubricate with ISO VG32 hydraulic oil during initial setup.
Allow 50mm clearance behind end covers for cushion adjustment.
| Property | Property Value |
|---|---|
| sku | SAID100AX300 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | 300mm |
