Airtac SAID100 Double Rod Cylinder SAID100AX30S
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX30S Twin Axis Cylinder Technical Details
- Model: SAID100AX30S
- Type: Double rod compact cylinder with guide rails
- Bore size: Ø100mm
- Stroke: 30mm (standard), customizable up to 500mm
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-750 mm/s
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable air cushion at both ends
- Port size: Rc1/4 (G1/4 optional)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR + Polyurethane combination
- Mounting options: Front flange (NFSE), rear flange (NFSL), or foot mounting
- Weight: 6.8 kg (without accessories)
- Dimensions: 290mm(L) × 160mm(W) × 160mm(H) (at mid-stroke)
- ISO standard: 15552 compliant
- Accessories: Built-in magnet for position sensing (D-M9N type)
High-rigidity twin shaft cylinder designed for precision linear motion requiring exceptional lateral load capacity. Features dual chrome-plated guide rods (Ø20mm) with preloaded ball bushings for zero rotational play. The symmetrical design minimizes deflection during high moment applications, with IP65 protection against particulate ingress.
- Automated material handling systems
- Precision press tooling operations
- Semiconductor wafer handling robots
- Heavy-duty clamping fixtures
- Vertical lift mechanisms in automotive assembly
Installation protocol:
Maintain 0.05mm maximum misalignment during mounting. Use alignment jigs for multi-cylinder synchronization. Lubricate with ISO VG32 hydraulic oil during initial installation. Allow 15-minute run-in period at 0.3MPa before full load operation.
| Property | Property Value |
|---|---|
| sku | SAID100AX30S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | 30mm |
