Airtac SAID100 Double Rod Cylinder SAID100AX325S
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX325S Double Rod Cylinder Specifications
- Model: SAID100AX325S
- Type: ISO 15552 compliant double rod cylinder
- Bore size: Ø100 mm
- Stroke: 325 mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Piston rod diameter: Ø25 mm (both rods)
- Mounting style: Basic type (ISO 15552 MF1) with optional accessory brackets
- Port size: G3/8
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to +80℃
- Weight: 6.5 kg (excluding accessories)
- Dimensions: 425mm(L) × 140mm(W) × 125mm(H)
- Rod end threads: M16×1.5 (both ends)
- Position detection: Magnet embeddable (sensor not included)
High-rigidity double rod cylinder designed for precision linear motion requiring anti-rotation stability. Features chrome-plated piston rods with integrated scrape ring to prevent contamination. Optional shock absorbers available for high-speed applications (>1 m/s). Requires ISO 8573-1:2010 class 4-4-3 compressed air quality.
- Automated assembly line positioning systems
- CNC machine tool clamping mechanisms
- Automotive welding fixture actuators
- Material handling transfer units
- Glass processing equipment
Installation note:
Ensure parallel alignment of both rod ends during mounting. Use flexible couplings
when connecting to driven components. Lubricate through air supply (ISO VG32 recommended)
if not using non-lube seals. Maximum side load capacity: 850N at full extension.
| Property | Property Value |
|---|---|
| sku | SAID100AX325S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | 325mm |
