Airtac SAID200 Double Rod Cylinder SAID200X120S
2. Asymmetric bidirectional sealing structure for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Cross-shaped aluminum tube construction without tie rods, offering superior corrosion resistance; External sensor mounting grooves enable quick and convenient sensor installation;
4. Smooth adjustable cushioning mechanism for stable operation;
5. Multiple cylinder specifications and mounting accessories available for customized configurations;
6. High-temperature resistant sealing materials ensure operational temperature range of 0-150℃.
Category: Double Rod Cylinder | Brand: AIRTAC | Series: SAID200
AirTAC SAID200X120S Dual Rod Cylinder Technical Details
- Full model designation: SAID200X120S
- Bore size: Ø20 mm (ISO 6432 standard)
- Stroke: 120 mm (±0.5mm tolerance)
- Operating pressure: 0.05-1.0 MPa (7-145 PSI)
- Cushioning type: Adjustable rubber buffers (both ends)
- Rod diameter: Ø10 mm chrome-plated steel
- Mounting style: Standard MF1 (front flange) with dual rod support
- Port size: M5x0.8 (G1/8 optional)
- Operating temperature: -10℃ to 80℃ (NBR seals)
- Ambient humidity: ≤95% RH (non-condensing)
- Piston speed: 50-750 mm/s (optimal range 100-500 mm/s)
- Weight: 1.25 kg (without accessories)
- Dimensions:
- Length: 229 mm (including rods)
- Body width: 32 mm
- Height: 50 mm (flange base to top)
- Rod center distance: 25 mm
- Material composition:
- Barrel: Aluminum alloy hard anodized
- End caps: Die-cast aluminum
- Rod guard: Stainless steel sleeves
Precision dual-rod cylinder engineered for high moment resistance and enhanced lateral load capacity. Features synchronized dual piston rods that eliminate rotational torque, making it ideal for applications requiring exceptional directional stability. The through-rod design allows symmetrical force transmission and optional position sensing integration.
- Precision glass handling systems (photovoltaic panel production)
- Semiconductor wafer clamping mechanisms
- CNC tool changer positioning
- Automated optical inspection (AOI) equipment
- High-speed sorting gates in packaging lines
Installation protocol:
Maintain parallel alignment of dual rods using precision jigs during mounting.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Recommend using rod end supports for strokes exceeding 150mm.
| Property | Property Value |
|---|---|
| sku | SAID200X120S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Cushion Stroke | <50mm> |
| Bore Diameter | <200mm> |
| Stroke | 120mm |
